System And Components
507-7423 LINES GP-STEERINGS/N HL91-UP; RG91-UP
Group No: 507-7423
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1757904 | 1 SEAL-O-RING | 1 | |
| 8T4184 | 2 BOLT (M12X1.75X45-MM) | 8 | |
| 8T4186 | 3 BOLT (M10X1.5X40-MM) | 2 | |
| 8T4910 | 4 BOLT (M12X1.75X60-MM) | 2 | |
| 8S0024 | 5 CLIP (TAB) | 1 | |
| 8T4192 | 6 BOLT (M12X1.75X25-MM) | 4 | |
| 1P3703 | 7 SEAL-RECTANGULAR | 4 | |
| 2K2939 | 8 SEAL-O-RING | 1 | |
| 5P7464 | 9 CLIP (SLOT) | 1 | |
| 5P7465 | 10 CLIP (TAB) | 1 | |
| 6V0400 | 11 FLANGE-HALF | 8 | |
| 7G3832 | 12 GROMMET | 1 | |
| 7G3833 | 13 CLIP (TAB) | 1 | |
| 7G3834 | 14 CLIP (SLOT) | 1 | |
| 7K6058 | 15 BOLT-12 POINT HEAD (1/2-13X2.5-IN) | 6 | |
| 8T4121 | 16 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4123 | 17 WASHER (22X35X3.5-MM THK) | 2 | |
| 8T4136 | 18 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4223 | 19 WASHER-HARD (13.5X25.5X3-MM THK) | 20 | |
| 8T4983 | 20 CLAMP-HOSE | 4 | |
| 8T7934 | 21 WASHER-HARD (11X21X5-MM THK) | 4 | |
| 8T7971 | 22 WASHER-HARD (13.5X25.5X5-MM THK) | 4 | |
| 8T9402 | 23 CLAMP-HOSE | 4 | |
| 5T6374 | 24 SPACER (11X20X40-MM THK) | 1 | |
| 1488390 | 25 ELBOW AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8626 | ELBOW | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1645641 | 26 TEE AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1287625 | TEE | 1 | |
| 2609174 | 27 CONNECTOR AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 7J1908 | SEAL | 1 | |
| 1095815 | CONNECTOR | 1 | |
| 3309751 | 28 FITTING AS | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 9X3962 | FITTING | 1 | |
| 3557217 | 29 STUD (M10X1.5X90-MM) | 1 | |
| 3737039 | 30 VALVE GP-CHECK | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 3895922 | 31 FILM-IDENTIFICATION (HYDRAULIC & XMSN OIL FILTER) | 1 | |
| 4168305 | 32 FILTER GP-OIL (HYDRAULIC, STEERING) | 1 | |
| 4851325 | 33 ELBOW AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 7J1908 | SEAL | 1 | |
| 7X7933 | ADAPTER-ELBOW | 1 | |
| 5165804 | 34 HOSE | 1 | |
| 5296539 | 35 BOLT AS | 2 | |
| 5416633 | 36 CLIP (LOOP) | 2 | |
| 1391398 | 37 CLIP (LOOP) | 1 | |
| 3445675 | 38 NUT (M10X1.5-THD) | 2 | |
| 3918044 | 39 CLIP (LOOP) | 1 | |
| 3N0759 | 40 RING-SEALING | 1 | |
| 4613125 | 41 PUMP GP-PISTON (STEERING) | 1 | |
| 4792171 | 42 BOLT AS | 4 | |
| 4832517 | 43 CLIP (LOOP) | 3 | |
| 5081826 | 44 HOSE AS | 1 | |
| 5081827 | 45 HOSE AS | 1 | |
| 5081830 | 46 HOSE AS | 1 | |
| 5095165 | 47 MOTOR GP-PISTON (STEERING) | 1 | |
| 5132374 | 48 HOSE | 1 | |
| 5165819 | 49 TUBE AS | 1 | |
| 5166869 | 50 TUBE AS | 1 | |
| 5167947 | 51 PLATE AS | 1 | |
| 5209790 | 52 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 5263291 | 53 ADAPTER | 1 | |
| 5283856 | 54 HOSE AS | 1 | |
| 5283857 | 55 HOSE AS | 1 | |
| 5527563 | 56 HOSE AS | 1 | |
| 6V7359 | 57 GROMMET (25-MM ID, 37-MM OD) | 1 | |
| 1064175 | 58 BOLT (M20X2.5X60-MM) | 2 | |
| 8S0023 | 59 CLIP (SLOT) | 1 | |
| 8T4183 | 60 BOLT (M12X1.75X40-MM) | 4 | |
| 8T4194 | 61 BOLT (M12X1.75X50-MM) | 6 |
