System And Components
452-4833 LINES GP-AIR -PLENUMS/N L4M1-UP
Group No: 452-4833
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4N0684 | 1 DOWEL | 4 | |
| 4T7968 | 2 GASKET | 1 | |
| 5P2228 | 3 BOLT (1/2-13X1-IN) | 4 | |
| 7C8199 | 4 FLANGE | 16 | |
| 2006547 | 5 GASKET | 2 | |
| 2043505 | 6 HOUSING | 1 | |
| 2043506 | 7 GASKET | 16 | |
| 2107750 | 8 PLATE | 1 | |
| 2200427 | 9 BRACKET | 1 | |
| 2412478 | 10 RETAINER | 1 | |
| 4506237 | 11 HOUSING | 1 | |
| 4536452 | 12 ADAPTER AS | 15 | |
| 4536453 | 13 ADAPTER AS | 1 | |
| 2071741 | RING-RETAINING | 1 | |
| 4355168 | CORE AS (FLAME ARRESTOR) | 1 | |
| 0S0509 | 14 BOLT (3/8-16X0.75-IN) | 36 | |
| 0S1590 | 15 BOLT (3/8-16X2-IN) | 16 | |
| 0S1621 | 16 BOLT (1/2-13X1-IN) | 2 | |
| 1553624 | 17 PLUG AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 9S4182 | PLUG (7/16-20-THD) | 1 | |
| 1653931 | 18 BOLT (3/8-16X1.75-IN) | 32 | |
| 1833407 | 19 PLUG AS | 3 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1S3730 | 20 COVER | 1 | |
| 4506673 | 21 HOUSING-AFTERCOOLER | 1 | |
| 4506674 | 22 PLATE AS | 1 | |
| 4S5898 | 23 SEAL-O-RING | 16 | |
| 5M2894 | 24 WASHER-HARD (10.2X18.5X2.5-MM THK) | 162 | |
| 5P0076 | 25 BOLT-12 POINT HEAD (3/8-16X1.5-IN) | 94 | |
| 5P8245 | 26 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 6V5101 | 27 SEAL-O-RING | 16 | |
| 8T4223 | 28 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 9X6458 | 29 WASHER-HARD (10.2X22.5X3-MM THK) | 16 |
