457-5423 LINES GP-HYDRAULIC FANS/N H3C1-UP; K3G1-UP

Group No: 457-5423

Part Number	Part Name	Qty
8T4136	1 BOLT (M10X1.5X25-MM)	1
8T4195	2 BOLT (M10X1.5X30-MM)	11
1837121	3 BOLT (M10X1.5X35-MM)	4
8T6685	4 BOLT (M10X1.5X110-MM)	1
2P1293	5 LOCKNUT (1-3/16-12-THD)	2
4J0520	6 SEAL-O-RING	1
4J5267	7 SEAL-O-RING	2
5P1076	8 WASHER-HARD (13.5X30X4-MM THK)	2
7X3391	9 WASHER-HARD (13.5X32X6-MM THK)	2
7X7729	10 WASHER (11X25X3-MM THK)	4
8C3205	11 FLANGE-HALF	4
8C3206	12 FLANGE-HALF	2
8T4121	13 WASHER-HARD (11X21X2.5-MM THK)	15
8T4137	14 BOLT (M10X1.5X20-MM)	1
3621320	15 BOLT (M12X1.75X35-MM)	4
8T7934	16 WASHER-HARD (11X21X5-MM THK)	1
9X2027	17 WASHER (11X18X2-MM THK)	1
1106349	18 FITTING AS (QUICK DISCONNECT)	1
3J7354	SEAL-O-RING	1
1275447	19 SPACER (10.5X20X12-MM THK)	2
1387500	20 SPACER (11X25X50-MM THK)	1
1488326	21 CONNECTOR AS	1
3J7354	SEAL-O-RING	1
6V8397	SEAL-O-RING	1
6V9872	CONNECTOR	1
1488336	22 CONNECTOR AS	1
3J1907	SEAL-O-RING	1
6V8397	SEAL-O-RING	1
6V8636	CONNECTOR	1
1654933	23 ELBOW AS	2
6V8990	ELBOW	1
6V9746	SEAL-O-RING	2
1803998	24 STUD (M10X1.5X55-MM)	2
2033847	25 BRACKET AS	1
2286089	26 PLUG (ROCKER SWITCH)	1
2796530	27 VALVE GP-SOLENOID (HYDRAULIC FAN)	1
2616728	COIL AS (10-VOLT)	1
2945374	28 PLATE	3
3091905	29 STUD-TAPERLOCK (M10X1.5X100-MM)	1
3445675	30 NUT (M10X1.5-THD)	3
4193723	31 HOSE AS	1
4228724	32 BRACKET	1
4377677	33 HOSE AS	1
4377678	34 HOSE AS	1
4563318	35 PUMP GP-GEAR (HYDRAULIC FAN)	1
4564196	36 MOTOR GP-GEAR (HYDRAULIC FAN)	1
4576566	37 HOSE AS	1
4576567	38 HOSE AS	1
4832517	39 CLIP (LOOP)	4
1772215	40 STRAP-DUAL CLAMP	3
2006345	41 SADDLE-MOUNTING (DUAL SWIVEL)	1
2042281	42 STRAP-CABLE	2
3918044	43 CLIP (LOOP)	1
4D7735	44 CLIP	2
6V0852	45 CAP-DUST	1
6V1889	46 CLIP (LOOP)	1
