System And Components
152-9153 CYLINDER BLOCK GPS/N 41Z12895-UP
Group No: 152-9153
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T6757 | 2 PLUG-PIPE | 3 | |
| 7W6534 | 3 PLUG-PIPE | 1 | |
| 9S8009 | 4 PLUG-O-RING | 1 | |
| 8T6763 | 5 PLUG-PIPE | 3 | |
| 1S9540 | 6 DOWEL (30.23 MM X 9.37 MM) | 2 | |
| 3S5496 | 7 SEAL-O-RING (9.53MM ID) | 2 | |
| 7W6492 | 8 PLUG-PIPE | 1 | |
| 0307571 | 9 BOLT (3/8-16X1.0IN) | 4 | |
| 4W8585 | 10 COVER | 1 | |
| 7W6081 | 11 GASKET | 1 | |
| 9X7378 | 12 SEAL-O-RING (8.92MM ID) | 1 | |
| 4N0683 | 13 DOWEL (15.88 X 31.88MM) | 4 | |
| 4N1650 | 14 DOWEL (1.25 IN LG X.376 DIA) | 2 | |
| 6I2981 | 15 PLATE-BLOCK | 1 | |
| 6I4024 | 16 GASKET-PLATE | 1 | |
| 8S9094 | 17 PLUG-ORIFICE | 1 | |
| 9S4190 | 18 PLUG-O-RING | 2 | |
| 1144427 | 19 SEAL-O-RING (19.18MM ID) | 2 | |
| 7X7732 | 20 PLUG-PIPE | 6 | |
| 4N0685 | 22 BEARING-SLEEVE | 6 | |
| 4N6658 | 23 BEARING-SLEEVE | 1 | |
| 8T6764 | 24 PLUG-PIPE | 1 | |
| 1527646 | 25 CYLINDER BLOCK GP | 1 | |
| 1195155 | 26 SEAL-O-RING (26.59MM ID) | 1 | |
| 1007399 | 27 PLUG | 2 | |
| 3E6747 | 28 SEAL-O-RING (32.99MM ID) | 2 | |
| 9S4182 | 29 PLUG-O-RING | 1 | |
| 1010523 | INSERT-LINER SEAT (5.21MM THK)(0.05MM US) | 6 |
