System And Components
1N-3970 DRIVE GP-ACCESSORYS/N 41Z18069-UP
Group No: 1N-3970
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7W8432 | 1 BEARING (ACCESSORY DRIVE) | 1 | |
| 1293948 | 2 SEAL-INTEGRAL | 1 | |
| 1N3973 | 3 GEAR (32 TEETH) | 1 | |
| 2W1838 | 4 TUBE AS | 1 | |
| 4N3852 | 5 COVER-RETAINER | 1 | |
| 2B2695 | 6 BOLT (5/16-18X.875 IN) | 12 | |
| 9M1974 | 7 WASHER-HARD (8.8X16X2MM THK) | 12 | |
| 6V8188 | 8 NUT (1/2-13 THD) | 2 | |
| 8T4223 | 9 WASHER-HARD (13.5X25.5X3MM THK) | 5 | |
| 1N3974 | 10 COUPLING | 1 | |
| 1N3975 | 11 COVER-RETAINER | 1 | |
| 3J7354 | 12 SEAL-O-RING (8.92MM ID) | 1 | |
| 8P1438 | 13 COVER | 1 | |
| 5P2566 | 14 BOLT (1/2-13X1.5 IN) | 2 | |
| 9H8872 | 15 GASKET | 1 | |
| 0307946 | 16 ELBOW | 1 | |
| 8L6557 | 17 CONNECTOR (37 DEGREE FLARED) | 1 | |
| 5P2424 | 18 BOLT (1/2-13X2.25 IN) | 1 | |
| 7K9197 | 19 ELBOW-SWIVEL (90 DEGREE) | 1 | |
| 1D4569 | 20 BOLT (1/2-13X4.25 IN) | 1 | |
| 9X8903 | STUD-TAPERLOCK | 1 | |
| 1D4719 | NUT-FULL (1/2-13 THD) | 1 | |
| 8T4223 | WASHER-HARD (13.5X25.5X3MM THK) | 1 |
