System And Components
109-2196 CARTRIDGE GP-TURBOCHARGERS/N 41Z9081-17171
Group No: 109-2196
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1092725 | 1 NUT | 1 | |
| 4P3624 | 2 WHEEL-COMPRESSOR | 1 | |
| 5S4556 | 3 INSERT | 1 | |
| 5S4546 | 4 RING-RETAINING | 1 | |
| 4P3627 | 5 HOUSING AS | 1 | |
| 5S5199 | PIN-GROOVED | 1 | |
| 4N7597 | 6 BEARING AS | 1 | |
| 4W7352 | 7 SLEEVE-SPACER | 1 | |
| 4W7355 | 8 PLATE-BACKING | 1 | |
| 4W7354 | 9 RING-PISTON (SEAL-PISTON RING) | 1 | |
| 1368317 | 10 SHAFT AS-TURBINE | 1 | |
| 4W7346 | 11 RING-THRUST | 2 | |
| 5S4549 | 12 DEFLECTOR-OIL | 1 | |
| 5P5757 | 13 SEAL-O-RING | 1 | |
| 4W7349 | 14 SLEEVE-FLINGER | 1 | |
| 4M8013 | 15 RING-PISTON | 1 | |
| 9M8915 | 16 RING-RETAINING | 4 | |
| 9S3263 | COMPOUND-LOCK | NULL | |
| 4W7344 | KIT-BEARING | 1 | |
| 7C2243 | KIT-BEARING (0.25MM OS OD) | 1 | |
| 7C2245 | KIT-BEARING (0.25MM US ID, 0.25MM OS OD) | 1 | |
| 7C2246 | KIT-BEARING (0.25MM US ID) | 1 | |
| 7C2247 | KIT-BEARING (0.25MM US ID, 0.51MM OS OD) | 1 |
