System And Components
178-7598 HOUSING GP-FRONTS/N BET1-UP
Group No: 178-7598
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1247340 | 1 HOUSING AS-FRONT | 1 | |
| 3E8044 | STUD (1/2-13X2.95-IN) | 1 | |
| 1887513 | 2 SENSOR GP-SPEED (SECONDARY, TIMING) | 1 | |
| 7C1445 | 3 COVER | 1 | |
| 2B2695 | 4 BOLT (5/16-18X0.875-IN) | 2 | |
| 9M1974 | 5 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 0S1594 | 6 BOLT (3/8-16X1-IN)(MARKED X) | 3 | |
| 5M2894 | 7 WASHER-HARD (10.2X18.5X2.5-MM THK) | 19 | |
| 0619455 | 8 SEAL-O-RING | 1 | |
| 0S1588 | 9 BOLT (3/8-16X1.25-IN) | 13 | |
| 1553629 | 11 GASKET | 1 | |
| 1669144 | 12 GASKET | 1 | |
| 3539977 | 13 PLATE AS-FRONT HOUSING | 1 | |
| 0L2070 | 14 BOLT (3/8-16X2.25-IN) | 1 | |
| 0T0055 | 15 BOLT (3/8-16X4.25-IN) | 4 | |
| 9S8752 | 16 NUT-FULL (3/8-16-THD) | 2 | |
| 0S1591 | 21 BOLT (3/8-16X1.5-IN) | 1 | |
| 1A5183 | 22 BOLT (3/8-16X4.75-IN) | 2 | |
| 1A5964 | 23 BOLT (3/8-16X4.5-IN) | 4 | |
| 3246804 | 24 COVER AS | 1 | |
| 1003098 | 25 COVER AS-PANEL | 1 | |
| 2H3755 | 28 BOLT (5/16-18X0.43-IN) | 2 | |
| 3P1155 | 29 SEAL-O-RING | 1 | |
| 1329770 | 30 SPACER AS | 1 | |
| 1W6448 | DOWEL | 2 | |
| 5P4255 | 31 BOLT-LOCKING (3/8-16X1-IN) | 8 | |
| 7X4805 | 32 SEAL-O-RING | 2 | |
| 2284947 | 33 SEAL-O-RING | 2 | |
| 1899266 | 34 SENSOR GP-SPEED (PRIMARY, TIMING) | 1 | |
| 9X6458 | 35 WASHER-HARD (10.2X22.5X3-MM THK) | 19 |
