System And Components
175-0262 LINES GP-WATERS/N BPC1-UP
Group No: 175-0262
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P4278 | 1 CLAMP-HOSE | 20 | |
| 2S2317 | 2 HOSE | 2 | |
| 3S2093 | 3 STRAP-CABLE | 5 | |
| 2446626 | 4 HOSE | 2 | |
| 4E9271 | 5 HOSE AS | 1 | |
| 6I2431 | 6 SEAL | 10 | |
| 6I2435 | 7 SPACER (80X108X25-MM THK) | 10 | |
| 6L8617 | 8 CAP-PRESSURE (7-PSI) | 1 | |
| 6N3303 | 9 HOSE | 1 | |
| 6S8620 | 10 CLAMP-HOSE | 2 | |
| 7T1159 | 11 HOSE AS | 1 | |
| 8C6866 | 12 CONNECTOR | 1 | |
| 8C6871 | 13 CONNECTOR | 2 | |
| 9M7958 | 14 CLAMP-HOSE | 4 | |
| 2126933 | 15 CLAMP | 2 | |
| 9Y9236 | 16 GAUGE-SIGHT | 1 | |
| 0617208 | 17 CLAMP-TUBE | 1 | |
| 1064572 | 18 HOSE-RADIATOR | 9 | |
| 1129486 | 19 RETAINER | 10 | |
| 1356928 | 20 ANGLE AS | 1 | |
| 1387524 | 21 TUBE AS | 1 | |
| 1487919 | 22 VALVE GP-RADIATOR DRAIN | 1 | |
| 1523832 | 23 HOSE AS | 1 | |
| 1546611 | 24 TUBE AS | 1 | |
| 1619903 | 25 TANK AS-RADIATOR TOP | 1 | |
| 1648911 | 26 HOSE AS | 1 | |
| 1750261 | 27 TANK AS-RADIATOR BOTTOM | 1 | |
| 1778014 | 28 ANGLE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 3 | |
| 1809267 | 29 TUBE AS | 1 | |
| 2048042 | 30 HOSE AS | 1 | |
| 2048043 | 31 HOSE AS | 1 | |
| 1488316 | 32 CONNECTOR AS | 3 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8647 | CONNECTOR | 1 | |
| 1504029 | 33 TEE AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 2 | |
| 6V8780 | TEE | 1 | |
| 2094580 | 34 CLAMP-T BOLT | 4 | |
| 2S1647 | 35 GROMMET | 1 | |
| 3E6753 | 36 GROMMET | 1 | |
| 3S8665 | 37 CLIP | 1 | |
| 4D7388 | 38 CLIP | 3 | |
| 4J5477 | 39 SEAL-O-RING | 1 | |
| 5P1076 | 40 WASHER-HARD (13.5X30X4-MM THK) | 1 | |
| 5P2228 | 41 BOLT (1/2-13X1-IN) | 1 | |
| 6B6205 | 42 SPACER (0.438X0.875X1.281-IN THK) | 1 | |
| 6D3479 | 43 CLIP | 4 | |
| 6V8398 | 44 SEAL-O-RING | 4 | |
| 7M8485 | 45 SEAL-O-RING | 1 | |
| 7X7729 | 46 WASHER (11X25X3-MM THK) | 30 | |
| 8K1433 | 47 GROMMET | 1 | |
| 8T4121 | 48 WASHER-HARD (11X21X2.5-MM THK) | 15 | |
| 8T4136 | 49 BOLT (M10X1.5X25-MM) | 5 | |
| 8T4137 | 50 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4195 | 51 BOLT (M10X1.5X30-MM) | 35 | |
| 8T6466 | 52 BOLT (M10X1.5X60-MM) | 1 | |
| 2094573 | 53 CLAMP-T BOLT | 4 | |
| 9X2133 | 54 HOSE (55 CM) | ||
| 7Y1976 | 55 HOSE-WATER (181 CM) | ||
| 5P1251 | 56 HOSE (216 CM) | ||
| 5P5727 | 57 SEAL (117 CM) |
