System And Components
196-5462 LINES GP-ENGINE OILS/N BET8000-UP
Group No: 196-5462
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2030147 | 1 TUBE AS | 1 | |
| 1W6137 | 2 TUBE AS | 1 | |
| 2P3760 | 3 GASKET | 1 | |
| 4N0826 | 4 ELBOW | 1 | |
| 4N1215 | 5 BODY-COOLER BYPASS (ENGINE OIL) | 1 | |
| 4N1216 | 6 TUBE-COOLER BYPASS | 1 | |
| 4N8150 | 7 SPRING | 1 | |
| 4P7373 | 8 TUBE AS | 1 | |
| 1P1367 | 9 PLUNGER | 1 | |
| 1152359 | 10 TUBE AS | 1 | |
| 1152365 | 11 BRACKET-TUBE | 1 | |
| 0L1351 | 12 BOLT (3/8-16X0.875-IN) | 3 | |
| 0S1588 | 13 BOLT (3/8-16X1.25-IN) | 4 | |
| 0S1591 | 14 BOLT (3/8-16X1.5-IN) | 2 | |
| 0S1594 | 15 BOLT (3/8-16X1-IN) | 10 | |
| 1090072 | 16 SEAL-O-RING | 1 | |
| 2K4973 | 17 LOCKNUT (3/8-16-THD) | 2 | |
| 2N3350 | 18 SEAL-O-RING | 2 | |
| 2P3761 | 19 COVER | 1 | |
| 3P0650 | 20 SEAL-O-RING | 2 | |
| 3E6790 | 21 SEAL-O-RING | 1 | |
| 5M2894 | 22 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 5P8068 | 23 SEAL-O-RING | 3 | |
| 8C5230 | 24 SEAL-O-RING | 2 | |
| 8T6765 | 25 PLUG-PIPE | 2 | |
| 9X6458 | 26 WASHER-HARD (10.2X22.5X3-MM THK) | 5 |
