System And Components
5V-7180 PLATFORM GPS/N 17Z1-659
Group No: 5V-7180
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3V3498 | 1 DOOR AS | 1 | |
| 3V0613 | BUMPER | 1 | |
| 2V9972 | 2 HINGE | 1 | |
| 1D4717 | NUT (3/8-16-THD) | 4 | |
| 5P1075 | 3 WASHER-HARD (10.2X22.5X3-MM THK) | 12 | |
| 3V7689 | 4 HANDLE AS | 3 | |
| 5K3546 | 5 PLUG-BUTTON | 1 | |
| 3L1979 | 6 PLUG | 1 | |
| 4V2027 | 7 PLUG-BUTTON | 2 | |
| 2G4815 | 8 PLUG | 1 | |
| 5M3062 | 9 BOLT (3/8-16X0.75-IN) | 8 | |
| 3V8113 | 10 SHEET AS | 1 | |
| 9F2978 | NUT-WELD (3/8-16-THD) | 2 | |
| 9F6445 | NUT-WELD (1/4-20-THD) | 3 | |
| 5V5801 | 11 DOOR AS-COMPENSATOR | 1 | |
| 4V6981 | 12 SCREW-BUTTON HEAD (1/4-20X0.75-IN) | 11 | |
| 2V7625 | 13 DOOR AS | 1 | |
| 5P9205 | 14 SEAL | ||
| 2V7635 | 15 COVER AS | 1 | |
| 6F7013 | 16 HANDLE | 1 | |
| 9F2978 | NUT-WELD (3/8-16-THD) | 2 | |
| 4S6336 | 17 PLUG-BUTTON | 1 | |
| 9V2810 | 18 PLATFORM AS | 1 | |
| 5P9205 | 19 SEAL | ||
| 5K9214 | 20 NUT (1/4-20-THD) | 4 | |
| 7V2849 | 21 PLATE | 1 | |
| 5V1121 | 22 PLATE | 1 | |
| 5V1122 | SPRING | 1 | |
| 2V7636 | 23 GASKET | 1 | |
| 2H3923 | 24 LOCKWASHER | 3 | |
| 7V6707 | 25 PLATE | 1 | |
| 6K2660 | 26 PLUG-BUTTON | 2 | |
| 8V7010 | 27 BUMPER (11.2MM) | 3 | |
| 3V2762 | 28 ROD | 1 | |
| 5P9205 | 29 SEAL | ||
| 4S6336 | 30 PLUG-BUTTON | 2 | |
| 3V0613 | 31 BUMPER | 6 | |
| 6S6646 | 32 PIN-COTTER | 2 | |
| 9V0182 | 33 ROD | 1 | |
| 3B4605 | 34 PIN-COTTER | 2 | |
| 9V0183 | 35 DOOR AS | 1 | |
| 1V6755 | LATCH AS | 2 | |
| 3V0760 | 36 COVER AS | 1 | |
| 8D5476 | 37 STUD-WELD (3/8-16X0.75-IN) | 4 | |
| 1D4717 | 38 NUT (3/8-16-THD) | 4 | |
| 5P1075 | 39 WASHER-HARD (10.2X22.5X3-MM THK) | 5 | |
| 5H4871 | 40 PLUG | 2 | |
| 5K3546 | 41 PLUG-BUTTON | 1 | |
| 5V5815 | 42 DOOR AS | 1 | |
| 0L1351 | 43 BOLT (3/8-16X0.875-IN) | 1 | |
| 3V7476 | KEY-HANDLE | 1 |
