System And Components
8R-5343 PLATFORM GPS/N 8CJ1-99999
Group No: 8R-5343
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3V3498 | 1 DOOR AS | 1 | |
| 2V9972 | 2 HINGE | 1 | |
| 6V8801 | NUT (3/8-16-THD) | 4 | |
| 5P1075 | 3 WASHER-HARD (10.2X22.5X3-MM THK) | 13 | |
| 3V7689 | 4 HANDLE AS | 2 | |
| 8V7010 | 5 BUMPER (11.2MM THK) | 3 | |
| 3L1979 | 6 PLUG (FOR 38.1MM DIA HOLE) | 1 | |
| 4V2027 | 7 PLUG-BUTTON (FOR 28.4MM DIA HOLE) | 1 | |
| 5K3546 | 8 PLUG-BUTTON | 2 | |
| 5M3062 | 9 BOLT (3/8-16X0.75-IN) | 8 | |
| 3V8113 | 10 SHEET AS | 1 | |
| 5V5801 | 11 DOOR AS-COMPENSATOR | 1 | |
| 4V6981 | 12 SCREW-BUTTON HEAD (1/4-20X0.75-IN) | 8 | |
| 9C3822 | 13 COVER | 1 | |
| 6V3884 | SCREW-HEX SOCKET (1/4-20X0.5-IN) | 4 | |
| 5P9205 | 14 SEAL | ||
| 2V7635 | 15 COVER AS | 1 | |
| 6F7013 | 16 HANDLE | 1 | |
| 4E1472 | 17 PLATE | 1 | |
| 8R8010 | 18 PLATFORM AS | 1 | |
| 9V7451 | NUT-WELD (1/4-20-THD) | 4 | |
| 5P9205 | 19 SEAL | ||
| 5K9214 | 20 NUT (1/4-20-THD) | 4 | |
| 7V2849 | 21 PLATE | 1 | |
| 5V1121 | 22 PLATE | 1 | |
| 5V1122 | SPRING | 1 | |
| 2V7636 | 23 GASKET | 1 | |
| 2H3923 | 24 LOCKWASHER | 2 | |
| 3V0613 | 25 BUMPER (9.6MM THK) | 8 | |
| 5S7379 | 26 BOLT (3/8-16X0.875-IN) | 1 | |
| 4S6336 | 27 PLUG-BUTTON | 2 | |
| 5V5815 | 28 DOOR AS | 1 | |
| 3V7476 | KEY-HANDLE | 1 |
