System And Components
4P-8474 LINES GP-TURBOCHARGER OILS/N 08Z69300-89170
Group No: 4P-8474 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8N1165 | 1 TUBE AS-OIL DRAIN | 1 | |
| 6I1330 | 2 TUBE AS-OIL | 1 | |
| 0S1571 | 3 BOLT (3/8-16X1.75-IN) | 2 | |
| 1S6595 | 4 GASKET-OIL SUPPLY | 1 | |
| 2M9780 | 5 SEAL-O-RING | 1 | |
| 1S4810 | 6 GASKET-OIL DRAIN | 1 | |
| 1A2029 | 7 BOLT (3/8-16X1.125-IN) | 5 | |
| 9M4849 | 8 SEAL-O-RING | 1 | |
| 5M2894 | 9 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 3K0360 | 10 SEAL-O-RING | 2 | |
| 8N1149 | 11 ELBOW | 1 | |
| 0L2070 | 12 BOLT (3/8-16X2.25-IN) | 1 | |
| 4M6480 | 13 GASKET | 1 | |
| 4W1512 | 14 SUPPORT AS-PUMP | 1 | |
| 8T6765 | 14A PLUG-PIPE (1/4-18-THD) | 1 | |
| 5H4279 | PLUG-CUP | 1 | |
| 9S4185 | 15 PLUG (3/4-16-THD) | 2 | |
| 8M5253 | 16 SEAL-O-RING | 1 | |
| 8M5248 | 17 SEAL-O-RING | 2 | |
| 9S8002 | 18 PLUG (7/16-20-THD) | 1 | |
| 3J7354 | 20 SEAL-O-RING | 1 | |
| 9M8406 | 21 CLIP (LOOP) | 1 | |
| 1H5514 | 22 BOLT (5/16-18X1.625-IN) | 1 | |
| 9M1974 | 23 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 9M4584 | 24 CONNECTOR | 1 |
