System And Components
253-9066 DOOR GP-CABS/N 9XG1-UP
Group No: 253-9066 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2T3754 | 1 GLASS | 1 | |
| 8W3925 | 3 STRAP | 1 | |
| 8Y6378 | 4 SEAL-HANDLE | 1 | |
| 9D9778 | 5 STRAP | 2 | |
| 1343062 | 6 STRIKER | 1 | |
| 1707709 | 7 HANDLE AS-DOOR | 1 | |
| 8Y4501 | SPRING-HANDLE | 1 | |
| 8Y6338 | BRACKET-MOUNTING | 2 | |
| 1994987 | 8 BAR | 1 | |
| 2117554 | 9 WINDOW GP-CAB | 1 | |
| 2195789 | 10 COVER | 1 | |
| 2255171 | 11 BRACKET | 1 | |
| 2539065 | 12 DOOR AS | 1 | |
| 8I2337 | HINGE | 1 | |
| 1889038 | BOSS (M6X1.6X40-MM) | 3 | |
| 2539155 | 13 ROD AS | 1 | |
| 2539156 | 14 LATCH AS | 1 | |
| 2539222 | 15 COVER | 1 | |
| 4L6454 | 16 BOLT (3/8-16X1-IN) | 3 | |
| 5P1075 | 17 WASHER-HARD (10.2X22.5X3-MM THK) | 1 | |
| 6V7357 | 18 BOLT (M6X1X25-MM) | 4 | |
| 6V7636 | 19 PIN AS-SPRING | 2 | |
| 7X2501 | 20 BOLT (1/4-20X1.25-IN) | 8 | |
| 8T4121 | 21 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4138 | 22 BOLT (M6X1X20-MM) | 1 | |
| 8T4205 | 23 WASHER-HARD (7.2X14.5X2-MM THK) | 16 | |
| 9X2042 | 24 SCREW-TRUSS HEAD (M6X1X12-MM) | 4 | |
| 9X2043 | 25 SCREW-TRUSS HEAD (M6X1X14-MM) | 5 | |
| 9X2045 | 26 SCREW-TRUSS HEAD (M6X1X20-MM) | 2 | |
| 9X8256 | 27 WASHER (6.6X12X2-MM THK) | 1 | |
| 5P5930 | 28 SEAL (0.8-M) | ||
| 5P5768 | 29 SEAL (3.3-M) | ||
| 5P5768 | 29A SEAL (2.2-M) | ||
| 1532681 | 30 SEAL (430-CM) |
