Assembly
100%

165-6158 HOOD & GUARD GPS/N 3SW1-UP

Group No: 165-6158
Part NumberPart NameQty
4E24361 CLAMP1
4M74702 GROMMET6
6W58173 SPRING1
6W58184 LATCH1
9K49395 BUMPER-STEM2
9X26166 SCREW-SOCKET (M8X1.25X16-MM)2
19565367 BRACKET2
13115868 ROD AS2
13869519 CAP AS1
1246569FASTENER7
1386954INSULATION1
8T3490NUT-WELD (M10X1.5-THD)6
1450060SEAL (100CM)
138695310 PANEL AS (LH)1
138695211 PANEL AS (RH)1
1246569FASTENER9
1246570WASHER (5.8X24.6X3.2-MM THK)9
1386955INSULATION (RH)1
1386956INSULATION (LH)1
1450060SEAL (124CM)
139956012 DOOR GP-HOOD (LH)1
139956113 DOOR GP-HOOD (RH)1
8T5413STUD-WELD (M10X1.5X25-MM)2
7F9223LOCKWASHER1
8T5004SCREW-MACHINE (1/4-28X0.375-IN)1
139956214 PANEL AS-TOP1
140597115 BRACKET AS1
150727016 GRILL AS1
8V1715SPACER (20.5X35X12-MM THK)1
8G0871HANDLE1
9V0453BUSHING-TERMINAL1
151205017 PIN AS1
151245218 GUARD AS1
151256719 LATCH AS1
156085420 PLATE AS1
167014321 ANGLE AS (RH)1
6V4604RIVET-POP2
163501022 ANGLE1
163798823 BUMPER AS8
3B206224 PIN1
3B461125 PIN-COTTER2
3B461526 PIN-COTTER2
5C726127 NUT (M8X1.25-THD)2
5P411628 WASHER-HARD (8.8X20.5X2-MM THK)2
7X772929 WASHER (11X25X3-MM THK)86
8T412130 WASHER-HARD (11X21X2.5-MM THK)5
8T413331 NUT (M10X1.5-THD)50
8T413632 BOLT (M10X1.5X25-MM)3
8T419533 BOLT (M10X1.5X30-MM)34
9V045034 PIN1
9X204035 SCREW-TRUSS HEAD (M10X1.5X25-MM)2
126847236 SEAL (7.5CM EA)4
5P748337 SEAL (.5M EA)2
5P748338 SEAL (1.29M EA)2
