System And Components
170-8027 PEDAL GP-BRAKE -PEDAL, LHS/N 3SW1-UP
Group No: 170-8027
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4E9664 | 1 PIN | 1 | |
| 6V8672 | 2 SCREW-MACHINE (M2.5X0.45X16-MM) | 2 | |
| 8T2899 | 3 SCREW-MACHINE (M2.5X0.45X6-MM) | 2 | |
| 0093101 | 4 RING-RETAINING | 3 | |
| 1056117 | 5 SWITCH AS-LIMIT (STOP LIGHT) | 1 | |
| 1056118 | 6 SWITCH AS-LIMIT (TMSN NEUTRALIZER) | 1 | |
| 1137752 | 7 PEDAL-BRAKE | 1 | |
| 1149493 | 8 HARNESS AS-WIRING (LEFT FOOT BRAKE BASE) | 1 | |
| 1152247 | 9 SPRING | 1 | |
| 1253295 | 10 SCREW-PAN HEAD (M2.5X0.45X12-MM) | 2 | |
| 1322169 | 11 INSULATOR | 1 | |
| 1536273 | 12 SETSCREW (M6X1X16-MM) | 1 | |
| 1610022 | 13 SWITCH AS-ADJUSTABLE (STOP LIGHT LIMIT) | 1 | |
| 1633926 | 14 ROLLER | 1 | |
| 1708024 | 15 BASE AS (LH) | 1 | |
| 7L8316 | 16 SETSCREW-SOCKET (10-32X2.54-IN) | 1 | |
| 0093101 | 16A RING-RETAINING | 1 | |
| 1149490 | 16B CAM-SWITCH | 1 | |
| 1150602 | 16C SPRING | 1 | |
| 1150603 | 16D KNOB | 1 | |
| 1151045 | 16E SETSCREW-SOCKET | 1 | |
| 1169895 | 16F PIN | 1 | |
| 1633927 | 16G PIN | 1 |
