System And Components
178-3186 PEDAL GP-BRAKE -PEDAL, LHS/N 3SW1225-99999
Group No: 178-3186
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3J7354 | 1 SEAL-O-RING | 1 | |
| 4E9664 | 2 PIN | 1 | |
| 6V2313 | 3 BOLT (M5X0.8X30-MM) | 2 | |
| 8S2225 | 4 SEAL-LIP TYPE | 1 | |
| 8T2899 | 5 SCREW-MACHINE (M2.5X0.45X6-MM) | 2 | |
| 0093101 | 6 RING-RETAINING | 3 | |
| 1056117 | 7 SWITCH AS-LIMIT (STOP LIGHT) | 1 | |
| 1137752 | 8 PEDAL-BRAKE | 1 | |
| 1152247 | 9 SPRING | 1 | |
| 1253295 | 10 SCREW-PAN HEAD (M2.5X0.45X12-MM) | 2 | |
| 1461892 | 11 HARNESS AS-BRAKE (STOP LIGHT) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 1461893 | 12 COVER | 1 | |
| 1462598 | 13 SEAL | 1 | |
| 1536273 | 14 SETSCREW (M6X1X16-MM) | 1 | |
| 1610022 | 15 SWITCH AS-ADJUSTABLE (STOP LIGHT LIMIT) | 1 | |
| 1872108 | 16 TERMINAL | 1 | |
| 2053582 | 17 ROLLER | 1 | |
| 2053583 | 18 PIN | 1 | |
| 2144863 | 19 SENSOR GP-POSITION (ROTARY)(LEFT BRAKE PEDAL) | 1 | |
| 4B4274 | 20 WASHER (5.5X13X1.2-MM THK) | 2 | |
| 5M6755 | 21 SCREW-MACHINE (10-24X0.562-IN) | 6 | |
| 9S8002 | 22 PLUG (7/16-20-THD) | 1 |
