System And Components
186-0156 PEDAL GP-BRAKE -PEDAL, LHS/N 3SW674-UP
Group No: 186-0156
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4E9664 | 1 PIN | 1 | |
| 6V8672 | 2 SCREW-MACHINE (M2.5X0.45X16-MM) | 2 | |
| 8S2225 | 3 SEAL-LIP TYPE | 1 | |
| 8T2899 | 4 SCREW-MACHINE (M2.5X0.45X6-MM) | 2 | |
| 0093101 | 5 RING-RETAINING | 3 | |
| 1056117 | 6 SWITCH AS-LIMIT (STOP LIGHT) | 1 | |
| 1056118 | 7 SWITCH AS-LIMIT (TRANSMISSION NEUTRALIZER) | 1 | |
| 1137752 | 8 PEDAL-BRAKE | 1 | |
| 1149493 | 9 HARNESS AS-WIRING (LEFT FOOT BRAKE BASE) | 1 | |
| 1028804 | KIT-RECEPTACLE (4-PIN) | 1 | |
| 1152247 | 10 SPRING | 1 | |
| 1253295 | 11 SCREW-PAN HEAD (M2.5X0.45X12-MM) | 2 | |
| 1322169 | 12 INSULATOR | 1 | |
| 1536273 | 13 SETSCREW (M6X1X16-MM) | 1 | |
| 1610022 | 14 SWITCH AS-ADJUSTABLE (STOP LIGHT LIMIT) | 1 | |
| 1633926 | 15 ROLLER | 1 | |
| 1634065 | 16 SEAL-O-RING | 1 | |
| 1872108 | 17 TERMINAL | 1 | |
| 1708583 | 18 SHAFT AS | 1 | |
| 7L8316 | 18A SETSCREW-SOCKET (10-32X2.54-IN) | 1 | |
| 0093101 | 18B RING-RETAINING | 1 | |
| 1149490 | 18C CAM-SWITCH | 1 | |
| 1150602 | 18D SPRING | 1 | |
| 1150603 | 18E KNOB | 1 | |
| 1151045 | 18F SETSCREW-SOCKET | 1 | |
| 1169895 | 18G PIN | 1 | |
| 8T0325 | 19 BOLT (M5X0.8X14-MM) | 6 | |
| 1140955 | 20 SEAL | 1 | |
| 3J7354 | 21 SEAL-O-RING | 2 | |
| 9S8002 | 22 PLUG (7/16-20-THD) | 2 | |
| 1141798 | 23 COVER | 1 |
