System And Components
111-0844 PEDAL GP-GOVERNORS/N 3SW1-99999
Group No: 111-0844
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1B8704 | 1 KEY-WOODRUFF | 1 | |
| 1V6341 | 2 SEAL (30.15MM OD) | 1 | |
| 2V7859 | 3 BEARING | 6 | |
| 2Y8075 | 4 PIN | 1 | |
| 3S2093 | 5 STRAP-CABLE | 3 | |
| 6W6662 | 6 GUIDE | 1 | |
| 8C3798 | 7 BOLT-LOCKING (M6X1X30-MM) | 2 | |
| 8C8990 | 8 SCREW-PAN HEAD | 1 | |
| 8R9039 | 9 SPRING | 1 | |
| 8T4181 | 10 BOLT (M6X1X20-MM) | 4 | |
| 8T4742 | 11 END-YOKE ROD | 1 | |
| 8V1612 | 13 SHAFT | 1 | |
| 9C5331 | 14 GUIDE | 1 | |
| 0950844 | 15 PIN-COTTER | 1 | |
| 1062433 | 16 PEDAL | 1 | |
| 1129649 | 17 HOUSING AS | 1 | |
| 6P0593 | BEARING-ROLLER | 1 | |
| 1129650 | 18 GASKET | 1 | |
| 1129653 | 19 COVER AS | 1 | |
| 6P0593 | BEARING-ROLLER | 1 | |
| 1129654 | 20 LEVER | 1 | |
| 1766767 | 21 CABLE AS | 1 | |
| 1150543 | 22 BAR | 1 | |
| 1185536 | 23 GASKET | 1 | |
| 5A3604 | 24 BOLT-SOCKET HEAD (M8X1.25X25-MM) | 1 | |
| 5C2890 | 25 NUT (M6X1-THD) | 2 | |
| 8T4197 | 26 BOLT (M8X1.25X40-MM) | 4 | |
| 8T4205 | 27 WASHER-HARD (7.2X14.5X2-MM THK) | 5 | |
| 8T4224 | 28 WASHER-HARD (8.8X16X2-MM THK) | 4 |
