System And Components
114-5171 LINES GP-WATERS/N 2TW125-UP
Group No: 114-5171
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P4278 | 1 CLAMP-HOSE | 14 | |
| 5P1265 | 2 HOSE (18-CM EACH) | 2 | |
| 9M7958 | 3 CLAMP-HOSE | 4 | |
| 3S2093 | 4 STRAP-CABLE | 5 | |
| 2446626 | 5 HOSE | 2 | |
| 4E9271 | 6 HOSE AS | 1 | |
| 6I2431 | 7 SEAL | 7 | |
| 6I2435 | 8 SPACER (80X108X25-MM THK) | 7 | |
| 6L8617 | 9 CAP-PRESSURE (7-PSI) | 1 | |
| 5P1259 | 10 HOSE (18-CM) | ||
| 6S8620 | 11 CLAMP-HOSE | 2 | |
| 7T1159 | 12 HOSE AS | 1 | |
| 8C6866 | 13 CONNECTOR | 1 | |
| 8C6871 | 14 CONNECTOR | 2 | |
| 9Y9236 | 15 GAUGE-SIGHT | 1 | |
| 0617208 | 16 CLAMP-TUBE | 1 | |
| 1064572 | 17 HOSE-RADIATOR | 6 | |
| 1129486 | 18 RETAINER | 7 | |
| 1224026 | 19 SPACER (13X25X25-MM THK) | 1 | |
| 1356928 | 20 ANGLE AS | 1 | |
| 1356929 | 21 ANGLE AS | 1 | |
| 1387524 | 22 TUBE AS | 1 | |
| 1487919 | 23 VALVE GP-RADIATOR DRAIN | 1 | |
| 1520961 | 24 ANGLE AS | 1 | |
| 1523426 | 25 TANK AS-RADIATOR BOTTOM | 1 | |
| 1523832 | 26 HOSE AS | 1 | |
| 1546611 | 27 TUBE AS | 1 | |
| 1619903 | 28 TANK AS-RADIATOR TOP | 1 | |
| 1648911 | 29 HOSE AS | 1 | |
| 1809267 | 30 TUBE AS | 1 | |
| 2047846 | 31 HOSE AS | 1 | |
| 2047847 | 32 HOSE AS | 1 | |
| 2094580 | 33 CLAMP-T BOLT | 4 | |
| 2126933 | 34 CLAMP | 2 | |
| 1488316 | 35 CONNECTOR AS | 3 | |
| 6V8647 | CONNECTOR | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 1504029 | 36 TEE AS | 1 | |
| 6V8780 | TEE | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 2 | |
| 2094573 | 37 CLAMP-T BOLT | 4 | |
| 2S1647 | 38 GROMMET | 1 | |
| 3E6753 | 39 GROMMET | 1 | |
| 3S8665 | 40 CLIP (LOOP) | 1 | |
| 4D7388 | 41 CLIP | 3 | |
| 4J5477 | 42 SEAL-O-RING | 1 | |
| 5P1076 | 43 WASHER-HARD (13.5X30X4-MM THK) | 5 | |
| 5P2228 | 44 BOLT (1/2-13X1-IN) | 1 | |
| 6B6205 | 45 SPACER (0.438X0.875X1.281-IN THK) | 1 | |
| 6D3479 | 46 CLIP (LOOP) | 5 | |
| 6V8398 | 47 SEAL-O-RING | 4 | |
| 7M8485 | 48 SEAL-O-RING | 1 | |
| 7X7729 | 49 WASHER (11X25X3-MM THK) | 21 | |
| 8K1433 | 50 GROMMET | 1 | |
| 8T4121 | 51 WASHER-HARD (11X21X2.5-MM THK) | 16 | |
| 8T4136 | 52 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4137 | 53 BOLT (M10X1.5X20-MM) | 5 | |
| 8T4139 | 54 BOLT (M12X1.75X30-MM) | 4 | |
| 8T4195 | 55 BOLT (M10X1.5X30-MM) | 26 | |
| 8T6466 | 56 BOLT (M10X1.5X60-MM) | 2 | |
| 9X2133 | 57 HOSE (55-CM) | ||
| 7Y1976 | 58 HOSE-WATER (180-CM) | ||
| 5P1251 | 59 HOSE (228-CM) | ||
| 5P5755 | 60 SEAL |
