System And Components
225-5033 DOOR GP-CABS/N 6SZ1-UP
Group No: 225-5033
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2T3754 | 1 GLASS | 1 | |
| 5T2998 | 2 HANDHOLD | 1 | |
| 6G9485 | 3 LEVER | 1 | |
| 6V2375 | 4 HANDLE AS-INSIDE | 1 | |
| 6V7636 | 5 PIN AS-SPRING | 4 | |
| 8T3848 | 6 STRIKER AS-LATCH | 1 | |
| 8W3925 | 7 STRAP | 1 | |
| 9D9778 | 8 STRAP | 2 | |
| 1707708 | 9 LATCH AS | 1 | |
| 1707709 | 10 HANDLE AS-DOOR | 1 | |
| 8Y4501 | SPRING-HANDLE | 1 | |
| 8Y6338 | BRACKET-MOUNTING | 2 | |
| 1994987 | 11 BAR | 1 | |
| 1995555 | 12 COVER | 1 | |
| 2117554 | 13 WINDOW GP-CAB | 1 | |
| 2195786 | 14 CHANNEL | 1 | |
| 2195789 | 15 COVER | 1 | |
| 2212857 | 16 LINK AS | 1 | |
| 2212858 | 17 LINK AS | 1 | |
| 2255032 | 18 DOOR AS | 1 | |
| 8I2337 | HINGE | 1 | |
| 1889038 | BOSS (M6X1.6X40-MM) | 3 | |
| 2200765 | LATCH AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 2 | |
| 2255171 | 19 BRACKET | 1 | |
| 1663777 | 20 SCREW-BUTTON HEAD (M6X1X28-MM) | 1 | |
| 4L6454 | 21 BOLT (3/8-16X1-IN) | 2 | |
| 5C2890 | 22 NUT (M6X1-THD) | 1 | |
| 6V7357 | 23 BOLT (M6X1X25-MM) | 4 | |
| 7X0447 | 24 NUT (7/16-14-THD) | 1 | |
| 7X2501 | 25 BOLT (1/4-20X1.25-IN) | 8 | |
| 8H3128 | 26 BOLT-SOCKET HEAD (1/4-20X0.625-IN) | 2 | |
| 8T4121 | 27 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4205 | 28 WASHER-HARD (7.2X14.5X2-MM THK) | 16 | |
| 8T4223 | 29 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 9X2042 | 30 SCREW-TRUSS HEAD (M6X1X12-MM) | 4 | |
| 9X2043 | 31 SCREW-TRUSS HEAD (M6X1X14-MM) | 11 | |
| 9X2045 | 32 SCREW-TRUSS HEAD (M6X1X20-MM) | 4 | |
| 5P5921 | 33 SEAL | ||
| 5P8310 | 34 SEAL | ||
| 5P6605 | 35 SEAL |
