System And Components
207-3149 CONSOLE GP-SIDES/N 1FM267-UP
Group No: 207-3149
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4K9429 | 1 RIVET-POP | 6 | |
| 5P7957 | 2 LANYARD | 1 | |
| 1466747 | 3 FILM-INFORMATION (24-VOLT) | 1 | |
| 1591549 | 4 CONVERTER-POWER (24-VOLT TO 12-VOLT) | 1 | |
| 1718658 | 5 CONSOLE GP-SIDE (FRONT) | 1 | |
| 1732052 | 6 RETAINER | 1 | |
| 1770795 | 7 SCREW-TRUSS HEAD (M5X0.8X10-MM) | 4 | |
| 1787907 | 8 HOLDER (LITERATURE) | 1 | |
| 1801327 | 9 CHANNEL AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 13 | |
| 8T8874 | NUT-WELD (M5X0.8-THD) | 4 | |
| 1805891 | 10 CONNECTOR | 1 | |
| 2019957 | 11 PLATE | 1 | |
| 2073150 | 12 CONSOLE GP-SIDE | 1 | |
| 1860817 | 13 WASHER-HARD (7X19X2-MM THK) | 2 | |
| 5C2890 | 14 NUT (M6X1-THD) | 2 | |
| 8K1433 | 15 GROMMET | 1 | |
| 8V7010 | 16 BUMPER | 1 | |
| 9X2042 | 17 SCREW-TRUSS HEAD (M6X1X12-MM) | 15 | |
| 6V3987 | 18 SEAL (.36M) |
