System And Components
1W-0717 LINES GP-ENGINE OILS/N 2GR1-8278; C8T152-2445
Group No: 1W-0717
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1N3333 | 1 TUBE | 1 | |
| 1N3873 | 2 TUBE | 1 | |
| 1P5764 | 3 FLANGE-HALF | 2 | |
| 2W1053 | 4 PLUG | 1 | |
| 2W1635 | 5 SPRING | 1 | |
| 2W1969 | 6 VALVE-BYPASS (OIL COOLER)(OIL COOLER) | 1 | |
| 2W7226 | 7 ADAPTER | 1 | |
| 3J1907 | 8 SEAL-O-RING | 2 | |
| 4B3140 | 9 COVER | 1 | |
| 4P2535 | 10 ELBOW AS | 1 | |
| 4W5596 | 11 COVER | 1 | |
| 4W5597 | 12 COVER | 1 | |
| 6B0933 | 13 SPACER (10.31X19.05X6.35-MM THK) | 4 | |
| 6B9202 | 14 SPRING | 2 | |
| 7C9217 | 15 ELBOW (OIL COOLER BYPASS) | 1 | |
| 7N5413 | 16 ELBOW | 1 | |
| 7N5416 | 17 ELBOW (OUTLET) | 1 | |
| 7N7697 | 18 PLUNGER AS | 2 | |
| 7M1808 | DOWEL | 1 | |
| 7W4379 | 19 TUBE AS | 1 | |
| 8N2929 | 20 COVER | 2 | |
| 8T6765 | 21 PLUG-PIPE (1/4-18-THD) | 1 | |
| 9S4191 | 22 PLUG (9/16-18-THD) | 2 | |
| 1008075 | 23 CLAMP AS | 1 | |
| 9S8752 | NUT-FULL (3/8-16-THD) | 2 | |
| 1113820 | 24 RING-RETAINING | 1 | |
| 2640450 | 25 CLAMP AS | 1 | |
| 9S8752 | NUT-FULL (3/8-16-THD) | 2 | |
| 3144866 | 26 SUPPORT-TUBE | 1 | |
| 0619456 | 27 SEAL-O-RING | 4 | |
| 0L1143 | 28 BOLT (3/8-16X2.5-IN) | 4 | |
| 0S1571 | 29 BOLT (3/8-16X1.75-IN) | 2 | |
| 0S1588 | 30 BOLT (3/8-16X1.25-IN) | 8 | |
| 0S1591 | 31 BOLT (3/8-16X1.5-IN) | 3 | |
| 0S1594 | 32 BOLT (3/8-16X1-IN) | 10 | |
| 1092332 | 33 SEAL-O-RING | 5 | |
| 1A1460 | 34 BOLT (1/2-13X2-IN) | 4 | |
| 1A2029 | 35 BOLT (3/8-16X1.125-IN) | 2 | |
| 1A5964 | 36 BOLT (3/8-16X4.5-IN) | 1 | |
| 1P3709 | 37 SEAL-RECTANGULAR | 1 | |
| 3B1915 | 38 BOLT (3/8-16X1.375-IN) | 2 | |
| 3P0655 | 39 SEAL-O-RING | 3 | |
| 5B2638 | 40 BOLT (3/8-16X5.25-IN) | 2 | |
| 5F4899 | 41 BOLT (3/8-16X5.5-IN) | 1 | |
| 5M2894 | 42 WASHER-HARD (10.2X18.5X2.5-MM THK) | 15 | |
| 5P1404 | 43 ADAPTER | 2 | |
| 5P4892 | 44 SEAL-O-RING | 1 | |
| 5P5846 | 45 SEAL-O-RING | 1 | |
| 5P7817 | 46 SEAL-O-RING | 1 | |
| 5P8245 | 47 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 6V1572 | 48 CLIP (SLOT) | 1 | |
| 6V1573 | 49 CLIP (TAB) | 1 | |
| 6V1574 | 50 GROMMET | 1 | |
| 6V3908 | 51 SEAL-O-RING | 1 | |
| 6V4589 | 52 SEAL-O-RING | 2 | |
| 6V5048 | 53 SEAL-O-RING | 1 | |
| 7X7730 | 54 PLUG-PIPE | 1 | |
| 8M9024 | 55 WASHER-HARD (10.2X22.5X5-MM THK) | 2 | |
| 9S4182 | 56 PLUG (7/16-20-THD) | 1 | |
| 9S8752 | 57 NUT-FULL (3/8-16-THD) | 2 | |
| 8T6762 | 58 PLUG-PIPE (1/2-14-THD) | 1 | |
| 0S1588 | 59 BOLT (3/8-16X1.25-IN) | 2 | |
| 5M2894 | 60 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 6V0852 | 61 CAP-DUST | 1 | |
| 6B5072 | 62 ADAPTER | 1 | |
| 6V3966 | 63 FITTING AS | 1 | |
| 6V0852 | 64 CAP-DUST | 1 | |
| 8T6762 | 65 PLUG-PIPE (1/2-14-THD) | 1 | |
| 6V3966 | 66 FITTING AS | 1 | |
| 1A5964 | 67 BOLT (3/8-16X4.5-IN) | 1 |
