System And Components
133-7075 HOUSING GP-FRONTS/N 5ED1-UP
Group No: 133-7075
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1694170 | 1 HOUSING AS-FRONT | 1 | |
| 2H5549 | 1A RING-RETAINING | 1 | |
| 8H9789 | 1B BALL BEARING | 2 | |
| 1159424 | 1C GEAR-PUMP DRIVE (34-TEETH) | 1 | |
| 2A3348 | 1D DOWEL | 2 | |
| 6V3538 | 1E DOWEL | 2 | |
| 3H7654 | 1F WASHER-HARD (13.5X22.5X3-MM THK) | 2 | |
| 8T0343 | 1G BOLT-SOCKET HEAD (M12X1.75X55-MM) | 2 | |
| 6V2317 | 2 BOLT (M8X1.25X30-MM) | 13 | |
| 6V5219 | BOLT (M8X1.25X40-MM) | 13 | |
| 9M1974 | 3 WASHER-HARD (8.8X16X2-MM THK) | 33 | |
| 2627131 | 4 COVER GP-FRONT HOUSING | 1 | |
| 1742475 | 5 SEAL-INTEGRAL | 1 | |
| 2628382 | 6 GASKET | 1 | |
| 1694166 | 7 SEAL GP-CRANKSHAFT | 1 | |
| 2203373 | 8 SEAL-RING | 1 | |
| 5P0537 | 9 WASHER-HARD (7.2X14.5X2-MM THK) | 5 | |
| 6V8225 | 10 NUT (M6X1-THD) | 5 | |
| 6V2317 | 11 BOLT (M8X1.25X30-MM) | 19 | |
| 3E8016 | 12 BOLT-SELF-LOCKING (M8X1.25X25-MM) | 1 |
