System And Components
170-1556 BOX GP-STORAGES/N BCR1-UP
Group No: 170-1556
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3V7689 | 1 HANDLE AS | 1 | |
| 4E9767 | 2 LID AS | 1 | |
| 8R9768 | HINGE | 1 | |
| 4E9771 | 3 BOX AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 6C3680 | 4 RIVET-POP | 4 | |
| 8Y6336 | 5 LATCH AS | 1 | |
| 1872064 | 6 BOX AS | 1 | |
| 1640427 | 7 MAT | 1 | |
| 1640428 | 8 PLATE AS | 1 | |
| 1640431 | 9 SHEET | 1 | |
| 1698366 | 10 LID AS | 1 | |
| 1701609 | 11 COVER | 1 | |
| 8T4121 | 12 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4137 | 13 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4185 | 14 BOLT (M10X1.5X50-MM) | 3 | |
| 8T4189 | 15 BOLT (M8X1.25X20-MM) | 5 | |
| 3E4353 | 16 WASHER-HARD (11X25X3-MM THK) | 5 | |
| 8V7010 | 17 BUMPER | 2 | |
| 9X2043 | 18 SCREW-TRUSS HEAD (M6X1X14-MM) | 10 | |
| 9X2616 | 19 SCREW-SOCKET (M8X1.25X16-MM) | 1 |
