193-4620 COVER GP-CYLINDER BLOCKS/N TX61-UP; BMA1-UP; 5GG9359-UP

Group No: 193-4620
Part NumberPart NameQty
9X20991 STUD (M8X1.25X52.75-MM)2
2W65442 COVER1
4P59183 CLIP2
4Y96524 GASKET3
7W38725 SLEEVE6
9X20976 STUD (M8X1.25-THD)1
11076187 BOLT AS3
6V5215BOLT (M8X1.25X16-MM)1
9M1974WASHER-HARD (8.8X16X2-MM THK)1
34249778 COVER-SIDE3
39855969 PLUG AS1
2385080SEAL-O-RING1
3603680PLUG (3/4-16-THD)1
130530110 CLIP1
4P758111 CLIP (LADDER)2
5P411612 WASHER-HARD (8.8X20.5X2-MM THK)1
5P797013 NUT (M8X1.25-THD)2
6V231714 BOLT (M8X1.25X30-MM)22
9M197415 WASHER-HARD (8.8X16X2-MM THK)26
517055316 GASKET1
