Assembly
100%

233-0209 CONTROL GP-ELECTROHYDRAULIC -JOYSTICK, 3-FUNCTION WITH AUTODIGS/N AYB638-UP

Group No: 233-0209
Part NumberPart NameQty
7K11811 STRAP-CABLE1
18920792 FILM-INSTRUCTION (MAINTENANCE)1
20582103 CUSHION AS1
20582114 PLATE1
20582125 CUSHION AS1
20860606 CONTROL GP-JOYSTICK (3-FUNCTION WITH AUTODIG)1
21067837 BRACKET AS1
6V9632NUT-WELD (M6X1-THD)2
21360168 BRACKET AS1
6V9632NUT-WELD (M6X1-THD)18
1889038BOSS (M6X1.6X40-MM)3
21360209 COVER1
233656710 FILM-CONTROL (JOYSTICK, 3-FUNCTION, AUTODIG)1
236252611 HARNESS AS-OPERATOR CONTROLS (JOYSTICK)1
7K1181STRAP-CABLE1
1552255KIT-CONNECTING PLUG (12-PIN)2
1552270KIT-CONNECTING PLUG (2-PIN)1
1552274KIT-CONNECTING PLUG (6-PIN)1
1800050KIT-CONNECTING PLUG (4-PIN)2
5C289012 NUT (M6X1-THD)2
6R765313 SCREW (M6X1X15-MM)2
8T413816 BOLT (M6X1X20-MM)2
8T420518 WASHER-HARD (7.2X14.5X2-MM THK)6
8T497019 BOLT (M6X1X14-MM)2
9X203820 WASHER (7X19X2-MM THK)4
9X204421 SCREW-TRUSS HEAD (M6X1X16-MM)16
5P612022 TRIM-EDGE (0.4-M)
5P612022A TRIM-EDGE (0.115-M EACH)
