System And Components
142-6198 LINES GP-STEERINGS/N BRL289-UP
Group No: 142-6198
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9X7456 | 1 GROMMET | 1 | |
| 6V0852 | 2 CAP-DUST | 1 | |
| 8T4985 | 3 CLAMP-HOSE | 12 | |
| 1319889 | 4 HOSE | 1 | |
| 1355050 | 5 HOSE | 2 | |
| 1530148 | 6 BLOCK-MANIFOLD | 1 | |
| 1530149 | 7 BRACKET | 1 | |
| 1536396 | 8 HOSE AS | 1 | |
| 1536399 | 9 HOSE AS | 1 | |
| 1536408 | 10 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 3 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 2 | |
| 9R2672 | BOSS-THREADED (M10X1.5X120-MM) | 2 | |
| 1536417 | 11 BLOCK | 1 | |
| 2169195 | 12 MANIFOLD | 1 | |
| 1616608 | 13 TUBE AS | 1 | |
| 1616903 | 14 PLATE | 1 | |
| 1629245 | 15 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1634501 | 16 HOSE AS | 1 | |
| 1634504 | 17 ANGLE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1634507 | 18 BRACKET AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 1640719 | 19 TUBE AS | 1 | |
| 1640720 | 20 TUBE | 1 | |
| 1640721 | 21 TUBE | 1 | |
| 1640722 | 22 TUBE AS | 1 | |
| 1711470 | 23 ELBOW | 1 | |
| 1922174 | 24 HOSE AS | 1 | |
| 2059342 | 25 CLAMP | 4 | |
| 2059343 | 26 COVER | 2 | |
| 2102120 | 27 HOSE AS | 1 | |
| 2102121 | 28 HOSE AS | 1 | |
| 2102455 | 29 HOSE AS | 1 | |
| 2102456 | 30 HOSE AS | 1 | |
| 2111645 | 31 HOSE AS | 1 | |
| 2119014 | 32 BRACKET AS | 2 | |
| 1065125 | 33 CLIP (SLOT) | 1 | |
| 1065126 | 34 CLIP (TAB) | 1 | |
| 1488327 | 35 CONNECTOR AS | 1 | |
| 6V8637 | CONNECTOR | ||
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488335 | 36 CONNECTOR AS | 2 | |
| 6V8635 | CONNECTOR | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488378 | 37 ELBOW AS | 2 | |
| 6V8724 | ELBOW | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1539624 | 38 PUMP GP-PISTON (STEERING) | 1 | |
| 1557328 | 39 ELBOW AS | 2 | |
| 6V9008 | ELBOW | 1 | |
| 5P7701 | SEAL-O-RING | 1 | |
| 8C3093 | SEAL-O-RING | 1 | |
| 1654931 | 40 ELBOW AS | 1 | |
| 6V8077 | ELBOW | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1H7339 | 41 SEAL-O-RING | 1 | |
| 1P3704 | 42 SEAL-RECTANGULAR | 7 | |
| 1P3706 | 44 SEAL-RECTANGULAR | 2 | |
| 1P4579 | 45 FLANGE-HALF | 4 | |
| 1P5767 | 46 FLANGE-HALF | 12 | |
| 1S0994 | 47 CLIP (LOOP) | 2 | |
| 3J1907 | 48 SEAL-O-RING | 1 | |
| 4J0520 | 49 SEAL-O-RING | 4 | |
| 4J0524 | 50 SEAL-O-RING | 3 | |
| 5F3106 | 51 SEAL-O-RING | 1 | |
| 5P7470 | 52 CLIP (SLOT) | 2 | |
| 5P7471 | 53 CLIP (TAB) | 2 | |
| 5P8182 | 54 GROMMET (46-MM ID) | 2 | |
| 6H3977 | 55 SEAL-O-RING | 1 | |
| 6V2235 | 56 CLIP | 1 | |
| 6V3965 | 57 FITTING (QUICK DISCONNECT) | 1 | |
| 7D1553 | 58 CLIP | 1 | |
| 7D7233 | 59 CLIP (LOOP) | 4 | |
| 7X0343 | 60 BOLT (5/8-11X1.25-IN) | 1 | |
| 7X2549 | 61 BOLT (M12X1.75X100-MM) | 6 | |
| 7X7729 | 62 WASHER (11X25X3-MM THK) | 8 | |
| 7Y1275 | 63 U-BOLT | 4 | |
| 8C3206 | 64 FLANGE-HALF | 8 | |
| 8T4121 | 65 WASHER-HARD (11X21X2.5-MM THK) | 31 | |
| 8T4122 | 66 WASHER-HARD (17X32X3.5-MM THK) | 1 | |
| 8T4133 | 67 NUT (M10X1.5-THD) | 9 | |
| 8T4136 | 68 BOLT (M10X1.5X25-MM) | 11 | |
| 8T4137 | 69 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4139 | 70 BOLT (M12X1.75X30-MM) | 14 | |
| 8T4176 | 71 BOLT (M12X1.75X90-MM) | 6 | |
| 8T4178 | 72 BOLT (M10X1.5X90-MM) | 6 | |
| 8T4183 | 73 BOLT (M12X1.75X40-MM) | 4 | |
| 8T4184 | 74 BOLT (M12X1.75X45-MM) | 12 | |
| 8T4192 | 75 BOLT (M12X1.75X25-MM) | 2 | |
| 8T4194 | 76 BOLT (M12X1.75X50-MM) | 24 | |
| 8T4195 | 77 BOLT (M10X1.5X30-MM) | 1 | |
| 8T4196 | 78 BOLT (M10X1.5X35-MM) | 16 | |
| 8T4223 | 79 WASHER-HARD (13.5X25.5X3-MM THK) | 71 | |
| 8T5041 | 80 BOLT (M12X1.75X120-MM) | 3 | |
| 8T7338 | 81 BOLT (M16X2X45-MM) | 2 | |
| 9X8257 | 83 WASHER (17.5X30X3.5-MM THK) | 2 | |
| 2062736 | 84 GUARD-HOSE (102CM) |
