System And Components
132-6135 LINES GP-STEERINGS/N BNH394-1366
Group No: 132-6135
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V0852 | 1 CAP-DUST | 2 | |
| 1654931 | 2 ELBOW AS | 1 | |
| 6V8077 | ELBOW | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1087550 | 4 CLIP | 2 | |
| 1274667 | 5 STRIP AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1348435 | 6 HOSE AS | 2 | |
| 1348459 | 7 PLATE | 2 | |
| 1419520 | 8 HOSE AS | 1 | |
| 1512680 | 9 PLATE AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 3 | |
| 1539624 | 10 PUMP GP-PISTON (STEERING) | 1 | |
| 1553169 | 11 TUBE AS | 1 | |
| 1553170 | 12 TUBE AS | 1 | |
| 1553172 | 13 TUBE AS | 1 | |
| 1553173 | 14 TUBE AS | 1 | |
| 7C6921 | 15 SPACER (11X20X22.8-MM THK) | 1 | |
| 1569627 | 16 HOSE AS | 1 | |
| 2169195 | 17 MANIFOLD | 2 | |
| 1989376 | 18 TUBE AS | 1 | |
| 1989375 | 19 TUBE AS | 1 | |
| 1622127 | 20 TUBE AS | 1 | |
| 1622128 | 21 TUBE AS | 1 | |
| 1628081 | 22 HOSE AS | 2 | |
| 1628455 | 23 HOSE AS | 1 | |
| 1635442 | 24 BRACKET AS | 1 | |
| 1635596 | 25 MANIFOLD | 1 | |
| 1419521 | 27 HOSE AS | 1 | |
| 9S4191 | 29 PLUG (9/16-18-THD) | 1 | |
| 1488327 | 30 CONNECTOR AS | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488353 | 31 ELBOW AS | 1 | |
| 6V9001 | ELBOW | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488443 | 32 TEE AS | 1 | |
| 7X2459 | ADAPTER-TEE | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1P3703 | 33 SEAL-RECTANGULAR | 8 | |
| 1P3704 | 34 SEAL-RECTANGULAR | 6 | |
| 1P4579 | 36 FLANGE-HALF | 4 | |
| 1P4584 | 37 FLANGE-HALF | 4 | |
| 1P5767 | 38 FLANGE-HALF | 4 | |
| 1S0724 | 39 CLIP | 4 | |
| 3J1907 | 40 SEAL-O-RING | 1 | |
| 4J0519 | 41 SEAL-O-RING | 4 | |
| 4J0524 | 42 SEAL-O-RING | 2 | |
| 4J5267 | 43 SEAL-O-RING | 8 | |
| 5F3106 | 44 SEAL-O-RING | 1 | |
| 6V1572 | 45 CLIP (SLOT) | 1 | |
| 6V1573 | 46 CLIP (TAB) | 1 | |
| 5P7703 | 47 GROMMET (52-MM ID) | 1 | |
| 6D4246 | 48 CLIP (LOOP) | 1 | |
| 6J2680 | 49 SEAL-O-RING | 3 | |
| 1645567 | 50 COUPLER AS-QUICK DISCONNECT (MALE) | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 7X0343 | 52 BOLT (5/8-11X1.25-IN) | 1 | |
| 7X0584 | 53 WASHER-HARD (13.5X20.5X2-MM THK) | 8 | |
| 7X2549 | 54 BOLT (M12X1.75X100-MM) | 8 | |
| 8C3205 | 55 FLANGE-HALF | 16 | |
| 8T4121 | 57 WASHER-HARD (11X21X2.5-MM THK) | 79 | |
| 8T4136 | 58 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4137 | 59 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4139 | 60 BOLT (M12X1.75X30-MM) | 4 | |
| 8T4183 | 61 BOLT (M12X1.75X40-MM) | 16 | |
| 8T4184 | 62 BOLT (M12X1.75X45-MM) | 8 | |
| 8T4186 | 63 BOLT (M10X1.5X40-MM) | 16 | |
| 8T4194 | 64 BOLT (M12X1.75X50-MM) | 8 | |
| 8T4195 | 65 BOLT (M10X1.5X30-MM) | 4 | |
| 8T4196 | 66 BOLT (M10X1.5X35-MM) | 32 | |
| 8T4223 | 67 WASHER-HARD (13.5X25.5X3-MM THK) | 53 | |
| 8T4648 | 68 BOLT (M12X1.75X70-MM) | 8 | |
| 8T4956 | 69 BOLT (M12X1.75X35-MM) | 8 | |
| 8T6466 | 71 BOLT (M10X1.5X60-MM) | 24 | |
| 8T6868 | 72 BOLT (M12X1.75X80-MM) | 1 | |
| 8T7338 | 73 BOLT (M16X2X45-MM) | 2 | |
| 9S6803 | 74 CLAMP | 2 | |
| 9X8257 | 75 WASHER (17.5X30X3.5-MM THK) | 3 |
