System And Components
132-6135 LINES GP-STEERINGS/N BNH1367-UP
Group No: 132-6135
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0A3721 | 1 CLIP | 4 | |
| 6V0852 | 2 CAP-DUST | 3 | |
| 0910081 | 3 SPACER (10.5X20X10-MM THK) | 1 | |
| 1087550 | 4 CLIP | 2 | |
| 1164731 | 5 ELBOW | 4 | |
| 1274667 | 6 STRIP AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1348459 | 7 PLATE | 2 | |
| 1419520 | 8 HOSE AS | 1 | |
| 1419521 | 9 HOSE AS | 1 | |
| 1434158 | 10 CLIP | 2 | |
| 1512680 | 11 PLATE AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 3 | |
| 1569627 | 12 HOSE AS | 1 | |
| 1622127 | 13 TUBE AS | 1 | |
| 1622128 | 14 TUBE AS | 1 | |
| 1628455 | 15 HOSE AS | 1 | |
| 1635442 | 16 BRACKET AS | 1 | |
| 1635596 | 17 MANIFOLD | 1 | |
| 1654931 | 18 ELBOW AS | 1 | |
| 6V8077 | ELBOW | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 2169195 | 19 MANIFOLD | 2 | |
| 2416215 | 20 ELBOW AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8076 | ELBOW | 1 | |
| 2478531 | 21 TUBE AS | 1 | |
| 2478532 | 22 TUBE AS | 1 | |
| 2478536 | 23 HOSE AS | 1 | |
| 2478537 | 24 HOSE AS | 1 | |
| 2478538 | 25 HOSE AS | 1 | |
| 2521285 | 26 TUBE AS | 1 | |
| 2521286 | 27 TUBE AS | 1 | |
| 2534280 | 28 ELBOW | 2 | |
| 1488353 | 29 ELBOW AS | 1 | |
| 6V9001 | ELBOW | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488378 | 30 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1536236 | 31 REDUCER AS | 2 | |
| 6V8946 | REDUCER | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1539624 | 32 PUMP GP-PISTON (STEERING) | 1 | |
| 1645567 | 33 COUPLER AS-QUICK DISCONNECT (MALE) | 3 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2478529 | 34 TUBE AS | 1 | |
| 2478530 | 35 TUBE AS | 1 | |
| 2478535 | 36 HOSE AS | 1 | |
| 1P3702 | 37 SEAL-RECTANGULAR | 6 | |
| 1P3703 | 38 SEAL-RECTANGULAR | 2 | |
| 1P3704 | 39 SEAL-RECTANGULAR | 6 | |
| 1P4579 | 40 FLANGE-HALF | 4 | |
| 1P4584 | 41 FLANGE-HALF | 4 | |
| 1P5767 | 42 FLANGE-HALF | 4 | |
| 1S0994 | 43 CLIP (LOOP) | 1 | |
| 3J1907 | 44 SEAL-O-RING | 1 | |
| 4J0524 | 45 SEAL-O-RING | 2 | |
| 4J5267 | 46 SEAL-O-RING | 10 | |
| 5F3106 | 47 SEAL-O-RING | 1 | |
| 5K9090 | 48 SEAL-O-RING | 8 | |
| 5P7703 | 49 GROMMET (52-MM ID) | 1 | |
| 6J2680 | 50 SEAL-O-RING | 2 | |
| 6V1572 | 51 CLIP (SLOT) | 1 | |
| 6V1573 | 52 CLIP (TAB) | 1 | |
| 6V9746 | 53 SEAL-O-RING | 5 | |
| 7X0584 | 54 WASHER-HARD (13.5X20.5X2-MM THK) | 8 | |
| 7X2549 | 55 BOLT (M12X1.75X100-MM) | 8 | |
| 7Y3729 | 56 FLANGE-SPECIAL | 5 | |
| 8C3205 | 57 FLANGE-HALF | 2 | |
| 8T4121 | 58 WASHER-HARD (11X21X2.5-MM THK) | 55 | |
| 8T4136 | 59 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4139 | 60 BOLT (M12X1.75X30-MM) | 4 | |
| 8T4183 | 61 BOLT (M12X1.75X40-MM) | 18 | |
| 8T4184 | 62 BOLT (M12X1.75X45-MM) | 8 | |
| 8T4191 | 63 BOLT (M10X1.5X16-MM) | 1 | |
| 8T4194 | 64 BOLT (M12X1.75X50-MM) | 8 | |
| 8T4195 | 65 BOLT (M10X1.5X30-MM) | 12 | |
| 8T4196 | 66 BOLT (M10X1.5X35-MM) | 16 | |
| 8T4223 | 67 WASHER-HARD (13.5X25.5X3-MM THK) | 56 | |
| 8T4648 | 68 BOLT (M12X1.75X70-MM) | 8 | |
| 8T4956 | 69 BOLT (M12X1.75X35-MM) | 8 | |
| 8T6466 | 70 BOLT (M10X1.5X60-MM) | 24 | |
| 8T7338 | 71 BOLT (M16X2X45-MM) | 2 | |
| 9S4191 | 72 PLUG (9/16-18-THD) | 1 | |
| 9X6032 | 73 BOLT-SOCKET HEAD (M10X1.5X30-MM) | 16 | |
| 9X8257 | 74 WASHER (17.5X30X3.5-MM THK) | 2 |
