System And Components
199-1445 HOUSING GP-FRONTS/N BNT1-UP
Group No: 199-1445
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7C1445 | 1 COVER | 1 | |
| 1003098 | 2 COVER AS-PANEL | 1 | |
| 1669144 | 3 GASKET | 1 | |
| 1559524 | 4 SEAL-INTEGRAL | 1 | |
| 1751483 | 5 HOUSING AS-FRONT | 1 | |
| 3E8044 | 5A STUD (1/2-13X2.95-IN) | ||
| 3246804 | 6 COVER AS | 1 | |
| 3539979 | 7 PLATE AS-FRONT HOUSING | 1 | |
| 0619455 | 8 SEAL-O-RING | 1 | |
| 0L2070 | 9 BOLT (3/8-16X2.25-IN) | 1 | |
| 0S1588 | 10 BOLT (3/8-16X1.25-IN) | 11 | |
| 0S1594 | 11 BOLT (3/8-16X1-IN) | 3 | |
| 0T0055 | 12 BOLT (3/8-16X4.25-IN) | 4 | |
| 1A5183 | 13 BOLT (3/8-16X4.75-IN) | 2 | |
| 1A5964 | 14 BOLT (3/8-16X4.5-IN) | 4 | |
| 2B2695 | 15 BOLT (5/16-18X0.875-IN) | 2 | |
| 5M2894 | 16 WASHER-HARD (10.2X18.5X2.5-MM THK) | 23 | |
| 5P4255 | 17 BOLT-LOCKING (3/8-16X1-IN) | 8 | |
| 9M1974 | 18 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9S8752 | 19 NUT-FULL (3/8-16-THD) | 2 | |
| 9X6458 | 20 WASHER-HARD (10.2X22.5X3-MM THK) | 12 |
