System And Components
218-3833 CONTROL GP-ELECTROHYDRAULIC -JOYSTICK, 3-FUNCTIONS/N AXG696-UP
Group No: 218-3833
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 1 | |
| 1892079 | 2 FILM-INSTRUCTION (MAINTENANCE) | 1 | |
| 2058210 | 3 CUSHION AS | 1 | |
| 2058211 | 4 PLATE | 1 | |
| 2058212 | 5 CUSHION AS | 1 | |
| 2106783 | 6 BRACKET AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 2 | |
| 2136016 | 7 BRACKET AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 18 | |
| 1889038 | BOSS (M6X1.6X40-MM) | 3 | |
| 2136020 | 8 COVER | 1 | |
| 2268665 | 9 CONTROL GP-JOYSTICK (3-FUNCTION) | 1 | |
| 2336566 | 10 FILM-CONTROL (JOYSTICK, 3-FUNCTION) | 1 | |
| 2362526 | 11 HARNESS AS-OPERATOR CONTROLS (JOYSTICK) | 1 | |
| 7K1181 | STRAP-CABLE | 1 | |
| 1552255 | KIT-CONNECTING PLUG (12-PIN) | 2 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 1552274 | KIT-CONNECTING PLUG (6-PIN) | 1 | |
| 1800050 | KIT-CONNECTING PLUG (4-PIN) | 2 | |
| 5C2890 | 12 NUT (M6X1-THD) | 2 | |
| 6R7653 | 13 SCREW (M6X1X15-MM) | 2 | |
| 8T4138 | 16 BOLT (M6X1X20-MM) | 2 | |
| 8T4205 | 18 WASHER-HARD (7.2X14.5X2-MM THK) | 6 | |
| 8T4970 | 19 BOLT (M6X1X14-MM) | 2 | |
| 9X2038 | 20 WASHER (7X19X2-MM THK) | 4 | |
| 9X2044 | 21 SCREW-TRUSS HEAD (M6X1X16-MM) | 16 | |
| 5P6120 | 22 TRIM-EDGE |
