System And Components
233-0208 CONTROL GP-ELECTROHYDRAULIC -JOYSTICK, 2-FUNCTION WITH AUTODIGS/N AXG696-UP
Group No: 233-0208
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 1 | |
| 1892079 | 2 FILM-INSTRUCTION (MAINTENANCE) | 1 | |
| 2058210 | 3 CUSHION AS | 1 | |
| 2058211 | 4 PLATE | 1 | |
| 2136016 | 5 BRACKET AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 18 | |
| 1889038 | BOSS (M6X1.6X40-MM) | 3 | |
| 2136020 | 6 COVER | 1 | |
| 2206102 | 7 CONTROL GP-JOYSTICK (2-FUNCTION WITH AUTODIG) | 1 | |
| 2336565 | 8 FILM-CONTROL (JOYSTICK, 2-FUNCTION WITH AUTODIG) | 1 | |
| 2362526 | 9 HARNESS AS-OPERATOR CONTROLS (JOYSTICK) | 1 | |
| 1552255 | KIT-CONNECTING PLUG (12-PIN) | 2 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 1552274 | KIT-CONNECTING PLUG (6-PIN) | 1 | |
| 1800050 | KIT-CONNECTING PLUG (4-PIN) | 2 | |
| 8T8737 | PLUG-SEAL | 16 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 24 | |
| 7K1181 | STRAP-CABLE | 1 | |
| 2184935 | SUPPRESSOR-ARC | 1 | |
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(20-CM) | ||
| 6R7653 | 10 SCREW (M6X1X15-MM) | 2 | |
| 8T4205 | 11 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 8T4970 | 12 BOLT (M6X1X14-MM) | 2 | |
| 9X2044 | 13 SCREW-TRUSS HEAD (M6X1X16-MM) | 12 | |
| 5P6120 | 14 TRIM-EDGE (0.4-M) | ||
| 5P6120 | 14A TRIM-EDGE (0.2-M EACH) |
