System And Components
Assembly
100%

431-7288 LINES GP-TURBOCHARGER WATERS/N 8WM3148-UP

Group No: 431-7288
Part NumberPart NameQty
4P06931 CLAMP AS4
1081434GROMMET2
6K84202 LOCKNUT (1-1/16-12-THD)2
7F20603 LOCKNUT (7/8-14-THD)2
7N78784 PLATE-COVER8
10707445 BLOCK4
15374826 BRACKET2
15374997 TUBE AS2
15505158 ELBOW4
34192119 GASKET16
386338510 BRACKET1
386338611 BRACKET1
386622912 ELBOW AS2
2385081SEAL-O-RING1
2501497ELBOW1
386736513 BRACKET AS2
390908914 BRACKET AS2
391457215 BRACKET AS2
0L207016 BOLT (3/8-16X2.25-IN)2
0S159417 BOLT (3/8-16X1-IN)6
0S160818 BOLT (3/8-16X3.75-IN)4
272177719 WASHER-HARD (11X18.5X15-MM THK)16
365057820 CONNECTOR AS4
2P7636CONNECTOR (3/4-16 STR-THD)1
2385080SEAL-O-RING1
2A463921 BOLT (3/8-16X1.625-IN)20
2P129622 TEE2
2P132623 ELBOW-UNION (FLARED 90-DEG)2
353795425 GROMMET4
386735826 HOSE AS-WATER2
455477527 HOSE & TUBE AS2
192740229 HOSE AS2
386736630 HOSE & TUBE AS2
3B191531 BOLT (3/8-16X1.375-IN)14
5M289432 WASHER-HARD (10.2X18.5X2.5-MM THK)34
5P194533 REDUCER-FLARED4
5P715434 TEE-UNION2
6V325135 SEAL-O-RING2
8C855436 CONNECTOR2
8M902437 WASHER-HARD (10.2X22.5X5-MM THK)8
8T188938 CLIP (SLOT)4
8T189039 CLIP (TAB)4
8T412140 WASHER-HARD (11X21X2.5-MM THK)4
6B288241 SPACER (0.406X0.75X0.312-IN THK)2
030796442 ELBOW1
030796543 ELBOW1
