System And Components
225-6319 LINES GP-WATER -RADIATORS/N BTX1-328
Group No: 225-6319
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P1265 | 1 HOSE (17.78-CM EACH) | 2 | |
| 3S2093 | 2 STRAP-CABLE | 5 | |
| 2446626 | 3 HOSE | 2 | |
| 4E9271 | 4 HOSE AS | 1 | |
| 6B6205 | 5 SPACER (0.438X0.875X1.281-IN THK) | 1 | |
| 6L8617 | 6 CAP-PRESSURE (7-PSI)(RADIATOR) | 1 | |
| 5P1259 | 7 HOSE (23-CM) | ||
| 6S8620 | 8 CLAMP-HOSE | 2 | |
| 7T1159 | 9 HOSE AS | 1 | |
| 1716731 | 11 CONNECTOR AS | 2 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8C6871 | CONNECTOR | 1 | |
| 9M7958 | 12 CLAMP-HOSE | 4 | |
| 9Y9236 | 13 GAUGE-SIGHT | 1 | |
| 0617208 | 14 CLAMP-TUBE | 1 | |
| 1224026 | 15 SPACER (13X25X25-MM THK) | 1 | |
| 1356928 | 16 ANGLE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1487919 | 17 VALVE GP-RADIATOR DRAIN | 1 | |
| 1523832 | 18 HOSE AS | 1 | |
| 1619903 | 19 TANK AS-RADIATOR TOP | 1 | |
| 1648911 | 20 HOSE AS | 1 | |
| 1809267 | 21 TUBE AS | 1 | |
| 2094580 | 22 CLAMP-T BOLT | 4 | |
| 2126933 | 23 CLAMP | 2 | |
| 2256320 | 24 TUBE AS | 1 | |
| 2345132 | 25 TUBE AS | 1 | |
| 1488316 | 26 CONNECTOR AS | 2 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8647 | CONNECTOR | 1 | |
| 1504029 | 27 TEE AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 2 | |
| 6V8780 | TEE | 1 | |
| 2094573 | 28 CLAMP-T BOLT | 4 | |
| 2S1647 | 29 GROMMET | 1 | |
| 3E6753 | 30 GROMMET | 1 | |
| 3S8665 | 31 CLIP (LOOP) | 1 | |
| 4D7388 | 32 CLIP | 3 | |
| 5P1076 | 34 WASHER-HARD (13.5X30X4-MM THK) | 1 | |
| 5P2228 | 35 BOLT (1/2-13X1-IN) | 1 | |
| 6D3479 | 36 CLIP (LOOP) | 1 | |
| 6V8398 | 37 SEAL-O-RING | 2 | |
| 7M8485 | 38 SEAL-O-RING | 1 | |
| 7X7729 | 39 WASHER (11X25X3-MM THK) | 1 | |
| 8K1433 | 40 GROMMET | 1 | |
| 8T4121 | 41 WASHER-HARD (11X21X2.5-MM THK) | 12 | |
| 8T4136 | 42 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4137 | 43 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4195 | 44 BOLT (M10X1.5X30-MM) | 6 | |
| 8T6466 | 45 BOLT (M10X1.5X60-MM) | 2 | |
| 9X2133 | 46 HOSE (55-CM) | ||
| 7Y1976 | 47 HOSE-WATER (180-CM) | ||
| 5P1251 | 48 HOSE (223-CM) |
