System And Components
224-9455 AFTERCOOLER GP-AIRS/N BXY1-UP
Group No: 224-9455
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1588 | 1 BOLT (3/8-16X1.25-IN) | 4 | |
| 1013125 | 2 GASKET (AIR INLET MANIFOLD) | 1 | |
| 1679196 | 3 TUBE | 1 | |
| 1856334 | 4 ELBOW | 1 | |
| 3743545 | 5 CORE AS-AFTERCOOLER | 1 | |
| 2087448 | 6 CLAMP | 8 | |
| 2249454 | 7 TUBE | 1 | |
| 5M2894 | 8 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 5P1076 | 9 WASHER-HARD (13.5X30X4-MM THK) | 2 | |
| 7T8331 | 10 MOUNT AS | 4 | |
| 7X0590 | 11 WASHER-HARD (13.5X44.5X6-MM THK) | 8 | |
| 8T4244 | 12 NUT (M12X1.75-THD) | 2 | |
| 8T4648 | 13 BOLT (M12X1.75X70-MM) | 4 | |
| 8T6765 | 14 PLUG-PIPE (1/4-18-THD) | 1 | |
| 7E8630 | 15 HOSE-AIR INLET | 4 |
