System And Components
247-8540 LINES GP-STEERINGS/N BXY958-1899
Group No: 247-8540
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0A3721 | 1 CLIP | 4 | |
| 2B0941 | 2 SPACER (10.5X19X19-MM THK) | 1 | |
| 6V0852 | 3 CAP-DUST | 3 | |
| 1087550 | 4 CLIP | 2 | |
| 1095816 | 5 ELBOW | 2 | |
| 1274667 | 6 STRIP AS | 1 | |
| 1348459 | 7 PLATE | 2 | |
| 1419520 | 8 HOSE AS | 1 | |
| 1419521 | 9 HOSE AS | 1 | |
| 1434158 | 10 CLIP | 2 | |
| 1512680 | 11 PLATE AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 3 | |
| 1622127 | 12 TUBE AS | 1 | |
| 1622128 | 13 TUBE AS | 1 | |
| 1628455 | 14 HOSE AS | 1 | |
| 1635442 | 15 BRACKET AS | 1 | |
| 1635596 | 16 MANIFOLD | 1 | |
| 1654931 | 17 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8077 | ELBOW | 1 | |
| 2169195 | 18 MANIFOLD | 2 | |
| 2262045 | 19 HOSE AS | 1 | |
| 2416215 | 20 ELBOW AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8076 | ELBOW | 1 | |
| 2478536 | 21 HOSE AS | 1 | |
| 2478538 | 22 HOSE AS | 1 | |
| 2521285 | 23 TUBE AS | 1 | |
| 2534280 | 24 ELBOW | 2 | |
| 2577804 | 25 TUBE AS | 1 | |
| 2904821 | 26 HOSE AS | 2 | |
| 2904822 | 27 HOSE AS | 2 | |
| 2921312 | 28 HOSE AS | 2 | |
| 0858091 | 29 BOLT (M10X1.5X55-MM) | 8 | |
| 1488353 | 30 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9001 | ELBOW | 1 | |
| 1488378 | 31 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1488407 | 32 PLUG AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 1536236 | 33 REDUCER AS | 4 | |
| 6V8946 | REDUCER | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1539624 | 34 PUMP GP-PISTON (STEERING) | 1 | |
| 1645567 | 35 COUPLER AS-QUICK DISCONNECT (MALE) | 3 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 1P3702 | 36 SEAL-RECTANGULAR | 8 | |
| 1P3703 | 37 SEAL-RECTANGULAR | 2 | |
| 1P3704 | 38 SEAL-RECTANGULAR | 6 | |
| 1P4579 | 39 FLANGE-HALF | 4 | |
| 1P4584 | 40 FLANGE-HALF | 4 | |
| 1P5767 | 41 FLANGE-HALF | 4 | |
| 1S0994 | 42 CLIP (LOOP) | 1 | |
| 4J0524 | 43 SEAL-O-RING | 2 | |
| 4J5267 | 44 SEAL-O-RING | 8 | |
| 5F3106 | 45 SEAL-O-RING | 1 | |
| 5K9090 | 46 SEAL-O-RING | 4 | |
| 5P7703 | 47 GROMMET (52-MM ID) | 1 | |
| 6J2680 | 48 SEAL-O-RING | 2 | |
| 6V1572 | 49 CLIP (SLOT) | 1 | |
| 6V1573 | 50 CLIP (TAB) | 1 | |
| 6V9746 | 51 SEAL-O-RING | 9 | |
| 7X0584 | 52 WASHER-HARD (13.5X20.5X2-MM THK) | 8 | |
| 7X2549 | 53 BOLT (M12X1.75X100-MM) | 8 | |
| 7Y3729 | 54 FLANGE-SPECIAL | 7 | |
| 8C3205 | 55 FLANGE-HALF | 6 | |
| 8T4121 | 56 WASHER-HARD (11X21X2.5-MM THK) | 63 | |
| 8T4136 | 57 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4139 | 58 BOLT (M12X1.75X30-MM) | 4 | |
| 8T4183 | 59 BOLT (M12X1.75X40-MM) | 18 | |
| 8T4184 | 60 BOLT (M12X1.75X45-MM) | 8 | |
| 8T4191 | 61 BOLT (M10X1.5X16-MM) | 1 | |
| 8T4194 | 62 BOLT (M12X1.75X50-MM) | 8 | |
| 8T4195 | 63 BOLT (M10X1.5X30-MM) | 12 | |
| 8T4196 | 64 BOLT (M10X1.5X35-MM) | 32 | |
| 8T4223 | 65 WASHER-HARD (13.5X25.5X3-MM THK) | 56 | |
| 8T4648 | 66 BOLT (M12X1.75X70-MM) | 8 | |
| 8T4956 | 67 BOLT (M12X1.75X35-MM) | 8 | |
| 8T6466 | 68 BOLT (M10X1.5X60-MM) | 8 | |
| 8T7338 | 69 BOLT (M16X2X45-MM) | 2 | |
| 9X6032 | 70 BOLT-SOCKET HEAD (M10X1.5X30-MM) | 8 | |
| 9X8257 | 71 WASHER (17.5X30X3.5-MM THK) | 2 |
