System And Components
283-0140 LINES GP-PILOT -IMPLEMENTS/N H4C376-383
Group No: 283-0140
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7T9745 | 1 MANIFOLD-VALVE | 1 | |
| 8R5174 | 2 HOSE AS | 1 | |
| 8X6185 | 3 HOSE AS | 1 | |
| 9X6772 | 4 STRAP-CABLE | 3 | |
| 1121817 | 5 VALVE-BALL (LOWERING CONTROL) | 1 | |
| 1528340 | 6 VALVE GP-SOLENOID (24-VOLT)(TILT DUAL RELIEF) | 1 | |
| 1647891 | 7 HOSE AS | 1 | |
| 1656527 | 8 HOSE AS | 1 | |
| 1681968 | 9 TEE AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1266872 | TEE | 1 | |
| 1737455 | 10 VALVE GP-SOLENOID (LOAD SENSING) | 2 | |
| 1743931 | 11 ANGLE AS | 1 | |
| 2509855 | 12 HOSE AS | 1 | |
| 2513226 | 13 TUBE AS | 2 | |
| 2514091 | 14 PLATE AS | 3 | |
| 2717721 | 15 TUBE AS | 1 | |
| 2717722 | 16 TUBE AS | 1 | |
| 2717723 | 17 HOSE AS | 1 | |
| 2717724 | 18 TUBE AS | 1 | |
| 2880630 | 19 BRACKET | 1 | |
| 2880632 | 20 HOSE AS | 1 | |
| 2880633 | 21 HOSE AS | 1 | |
| 2880634 | 22 MANIFOLD | 1 | |
| 2880635 | 23 HOSE AS | 1 | |
| 2880636 | 24 HOSE AS | 1 | |
| 2918390 | 25 BRACKET AS | 1 | |
| 3139214 | 26 HOSE AS | 1 | |
| 3139578 | 27 HOSE AS | 1 | |
| 3139775 | 28 HOSE AS | 1 | |
| 3144182 | 29 HOSE AS | 1 | |
| 3151395 | 30 TUBE AS | 1 | |
| 3425982 | 31 TUBE AS | 1 | |
| 3152657 | 32 HOSE AS | 2 | |
| 3152658 | 33 HOSE AS | 1 | |
| 3152783 | 34 TUBE AS | 1 | |
| 3152784 | 35 TUBE AS | 1 | |
| 3168684 | 36 BRACKET | 2 | |
| 3175524 | 37 PLATE AS | 1 | |
| 3175525 | 38 PLATE AS | 1 | |
| 3175526 | 39 HOSE AS | 1 | |
| 0966166 | 40 WASHER-HARD (4.5X9X1-MM THK) | 4 | |
| 1223606 | 41 CLIP (LOOP) | 2 | |
| 1305300 | 42 CLIP | 2 | |
| 1488336 | 43 CONNECTOR AS | 3 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488338 | 44 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T0075 | CONNECTOR | 1 | |
| 1488353 | 45 ELBOW AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9001 | ELBOW | 1 | |
| 1488365 | 46 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8T6876 | ELBOW | 1 | |
| 1488366 | 47 ELBOW AS | 2 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8987 | ELBOW | 1 | |
| 1488367 | 48 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9850 | ELBOW | 1 | |
| 1488370 | 49 ELBOW AS | 2 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9851 | ELBOW | 1 | |
| 1488378 | 50 ELBOW AS | 5 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1488428 | 51 TEE AS | 3 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V8782 | TEE | 1 | |
| 1488433 | 52 TEE AS | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V9836 | TEE-SWIVEL | 1 | |
| 1488435 | 53 TEE AS | 3 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8781 | TEE | 1 | |
| 1488444 | 55 TEE AS-SWIVEL | 4 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V9837 | TEE-SWIVEL | 1 | |
| 1495452 | 56 UNION AS (STRAIGHT) | 3 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8994 | UNION (STRAIGHT) | 1 | |
| 1503033 | 57 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 8T0164 | ELBOW | 1 | |
| 1504043 | 58 CONNECTOR AS | 5 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9873 | CONNECTOR | 1 | |
| 1523411 | 59 ELBOW | 4 | |
| 1645544 | 60 ELBOW AS | 1 | |
| 3E2333 | ELBOW | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1645567 | 61 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2815968 | 62 ELBOW AS | 2 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8T5465 | ELBOW | 1 | |
| 3152656 | 63 HOSE AS | 1 | |
| 1B3057 | 64 CLIP | 10 | |
| 1S0994 | 65 CLIP (LOOP) | 1 | |
| 3G8054 | 66 CLIP (TAB) | 2 | |
| 3G8057 | 67 CLIP (SLOT) | 2 | |
| 5P7462 | 68 CLIP (SLOT) | 3 | |
| 5P7463 | 69 CLIP (TAB) | 3 | |
| 5P7464 | 70 CLIP (SLOT) | 3 | |
| 5P7465 | 71 CLIP (TAB) | 3 | |
| 6D4246 | 72 CLIP (LOOP) | 2 | |
| 6V0683 | 73 GROMMET | 3 | |
| 6V0852 | 74 CAP-DUST | 1 | |
| 6V0974 | 75 GROMMET | 2 | |
| 6V1249 | 76 GROMMET (22-MM ID) | 3 | |
| 6V8397 | 77 SEAL-O-RING | 1 | |
| 6V8398 | 78 SEAL-O-RING | 2 | |
| 6V9168 | 79 NUT (11/16-16-THD) | 5 | |
| 6V9830 | 80 CAP (ORFS) | 1 | |
| 7X7729 | 81 WASHER (11X25X3-MM THK) | 4 | |
| 8T0285 | 82 SCREW-MACHINE (M4X0.7X12-MM) | 4 | |
| 8T4121 | 83 WASHER-HARD (11X21X2.5-MM THK) | 33 | |
| 8T4133 | 84 NUT (M10X1.5-THD) | 3 | |
| 8T4136 | 85 BOLT (M10X1.5X25-MM) | 21 | |
| 8T4137 | 86 BOLT (M10X1.5X20-MM) | 9 | |
| 8T4183 | 87 BOLT (M12X1.75X40-MM) | 2 | |
| 8T4194 | 88 BOLT (M12X1.75X50-MM) | 1 | |
| 8T4195 | 89 BOLT (M10X1.5X30-MM) | 4 | |
| 8T4223 | 90 WASHER-HARD (13.5X25.5X3-MM THK) | 5 | |
| 8T4224 | 91 WASHER-HARD (8.8X16X2-MM THK) | 6 | |
| 8T4956 | 93 BOLT (M12X1.75X35-MM) | 2 | |
| 8T6869 | 94 BOLT (M8X1.25X60-MM) | 6 | |
| 8T4123 | 95 WASHER (22X35X3.5-MM THK) | 4 | |
| 6V9169 | 96 NUT (13/16-16-THD) | 2 | |
| 3154137 | 97 BRACKET | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 2 | |
| 1488364 | 98 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8625 | ELBOW | 1 |
