System And Components
229-8090 MUFFLER GPS/N B1M1-790
Group No: 229-8090
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4B5272 | 1 WASHER (12.7X31.7X2-MM THK) | 3 | |
| 6U5219 | 2 U-CLAMP AS | 1 | |
| 8T6431 | 3 ROD END | 2 | |
| 9N1941 | 4 CLAMP-V BAND | 1 | |
| 1420485 | 5 NUT (M10X1.5-THD) | 2 | |
| 1610695 | 6 MUFFLER AS | 1 | |
| 1732328 | 7 PIPE AS | 1 | |
| 1732331 | 8 PIPE AS | 1 | |
| 1753377 | 9 SUPPORT AS | 1 | |
| 1753380 | 10 PLATE | 2 | |
| 1754780 | 11 PLATE AS | 1 | |
| 1757262 | 12 PLATE | 1 | |
| 1759076 | 13 MOUNTING | 2 | |
| 1759077 | 14 PLATE | 1 | |
| 1759078 | 15 PLATE | 1 | |
| 1759079 | 16 ROD-LINK | 1 | |
| 1768102 | 17 CLAMP | 1 | |
| 1768232 | 18 TUBE AS | 1 | |
| 1768234 | 19 CLAMP | 2 | |
| 1768237 | 20 CLAMP | 1 | |
| 1974834 | 21 SEAL | 1 | |
| 1974835 | 22 PLATE-RETAINER | 1 | |
| 2021838 | 23 CLAMP-V BAND | 1 | |
| 2021839 | 24 CLAMP-V BAND | 2 | |
| 2053625 | 25 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 2112326 | 26 BOSS | 3 | |
| 2114635 | 27 PIPE-EXHAUST | 1 | |
| 2169945 | 28 PIPE GP-EXHAUST (TAIL) | 1 | |
| 2262659 | 29 WASHER-BELLEVILLE (13X29X3-MM THK) | 2 | |
| 2324836 | 30 SUPPORT AS | 1 | |
| 2341703 | 31 TUBE AS | 1 | |
| 5C7261 | 32 NUT (M8X1.25-THD) | 10 | |
| 5P1076 | 33 WASHER-HARD (13.5X30X4-MM THK) | 2 | |
| 6V7687 | 34 LOCKNUT (M12X1.75-THD) | 1 | |
| 6V7744 | 35 LOCKNUT (M10X1.5-THD) | 1 | |
| 6V8801 | 36 NUT (3/8-16-THD) | 4 | |
| 7X2537 | 37 BOLT (M8X1.25X35-MM) | 2 | |
| 7X2550 | 38 BOLT (M12X1.75X110-MM) | 1 | |
| 7X7729 | 39 WASHER (11X25X3-MM THK) | 4 | |
| 8T4121 | 40 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4184 | 41 BOLT (M12X1.75X45-MM) | 6 | |
| 8T4189 | 42 BOLT (M8X1.25X20-MM) | 8 | |
| 8T4192 | 43 BOLT (M12X1.75X25-MM) | 6 | |
| 8T4195 | 44 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4223 | 45 WASHER-HARD (13.5X25.5X3-MM THK) | 12 | |
| 8T4224 | 46 WASHER-HARD (8.8X16X2-MM THK) | 20 | |
| 8T6685 | 47 BOLT (M10X1.5X110-MM) | 1 |
