System And Components
252-8439 CYLINDER HEAD GPS/N THX1-UP
Group No: 252-8439
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W2715 | 1 LOCK-RETAINER | 24 | |
| 2A4429 | 2 LOCK-RETAINER | 24 | |
| 2604856 | 3 GUIDE-VALVE (STANDARD, EXHAUST) | 12 | |
| 2033237 | GUIDE-VALVE (0.13-MM OS, EXHAUST) | ||
| 2033238 | GUIDE-VALVE (0.5-MM OS, EXHAUST) | ||
| 1632478 | 4 SEAL-VALVE STEM | 12 | |
| 3893708 | 5 PLUG AS (MARKED Y) | 6 | |
| 3603679 | PLUG-CONNECTOR (9/16-18-THD) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3196237 | 6 PLUG AS (HEX HEAD) | 2 | |
| 2717442 | PLUG | 1 | |
| 2287096 | SEAL-O-RING | 1 | |
| 1906115 | 8 SPRING-VALVE (INNER) | 12 | |
| 1906117 | 9 SPRING-VALVE (OUTER) | 12 | |
| 2112134 | 10 RETAINER (VALVE SPRING) | 12 | |
| 2170609 | 11 SEAT-VALVE SPRING | 6 | |
| 4901726 | 12 VALVE-INLET | 12 | |
| 4901723 | 13 VALVE-EXHAUST | 12 | |
| 2418384 | 14 RETAINER (VALVE SPRING) | 12 | |
| 2418386 | 15 SPRING-VALVE (INNER) | 12 | |
| 2418385 | 16 SPRING-VALVE (OUTER) | 12 | |
| 2418387 | 17 SEAT | 6 | |
| 2595829 | 18 GUIDE-VALVE (STANDARD, INTAKE) | 12 | |
| 2543941 | GUIDE-VALVE (0.13-MM OS)(INTAKE) | ||
| 2543942 | GUIDE-VALVE (0.5-MM OS)(INTAKE) | ||
| 2418390 | 19 SEAL-VALVE STEM | 12 | |
| 3960405 | 21 PLUG AS | 2 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 3603680 | PLUG (3/4-16-THD) | 1 | |
| 8T6757 | 22 PLUG-PIPE | 2 |
