System And Components
202-2657 LINES GP-ENGINE OILS/N SBK1292-1395
Group No: 202-2657
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W2447 | 1 ADAPTER-OUTLET | 1 | |
| 2W1053 | 2 PLUG | 1 | |
| 2W1635 | 3 SPRING | 1 | |
| 3594123 | 4 ADAPTER | 1 | |
| 4W0530 | 5 RING-RETAINING | 1 | |
| 4W0531 | 6 RETAINER | 2 | |
| 4W4313 | 7 ADAPTER | 1 | |
| 4W4677 | 8 TUBE | 1 | |
| 6B0933 | 9 SPACER (10.31X19.05X6.35-MM THK) | 8 | |
| 6B9202 | 10 SPRING | 2 | |
| 7N7697 | 11 PLUNGER AS | 2 | |
| 7M1808 | DOWEL | 2 | |
| 8C3445 | 12 CAP-DUST | 1 | |
| 8N1991 | 13 RING-RETAINING | 1 | |
| 8N1992 | 14 RETAINER | 2 | |
| 8N2929 | 15 COVER | 2 | |
| 1008075 | 16 CLAMP AS | 2 | |
| 1113820 | 17 RING-RETAINING | 1 | |
| 3654215 | 18 ADAPTER | 1 | |
| 1244273 | 19 VALVE-BYPASS | 1 | |
| 1363296 | 20 FLANGE | 1 | |
| 1435184 | 21 PLUG-ADAPTER (3/4-14-THDX3/8-16-THD) | 1 | |
| 1467359 | 22 TUBE | 1 | |
| 1506612 | 23 ELBOW-OUTLET | 1 | |
| 1539963 | 24 RING | 1 | |
| 1916695 | 25 PLATE | 1 | |
| 1919310 | 26 COVER | 1 | |
| 2377623 | 27 SEAL-O-RING | 2 | |
| 2401919 | 28 TUBE AS | 1 | |
| 2445867 | 29 ELBOW | 1 | |
| 2456848 | 30 CLAMP AS | 2 | |
| 2474806 | 31 ELBOW | 1 | |
| 6V4368 | 32 SEAL-O-RING | 4 | |
| 0L1143 | 33 BOLT (3/8-16X2.5-IN) | 4 | |
| 0L1352 | 34 BOLT (3/8-16X3.25-IN) | 1 | |
| 0S1571 | 35 BOLT (3/8-16X1.75-IN) | 4 | |
| 0S1588 | 36 BOLT (3/8-16X1.25-IN) | 16 | |
| 0S1590 | 37 BOLT (3/8-16X2-IN) | 2 | |
| 0S1591 | 38 BOLT (3/8-16X1.5-IN) | 2 | |
| 0S1594 | 39 BOLT (3/8-16X1-IN) | 4 | |
| 0T0065 | 40 BOLT (3/8-16X3.5-IN) | 8 | |
| 1092332 | 41 SEAL-O-RING | 4 | |
| 1A2029 | 42 BOLT (3/8-16X1.125-IN) | 8 | |
| 6V1574 | 43 GROMMET | 1 | |
| 3P0653 | 44 SEAL-O-RING | 1 | |
| 3P0655 | 45 SEAL-O-RING | 1 | |
| 3S1546 | 46 NUT-FULL (7/16-14-THD) | 4 | |
| 4F8965 | 47 BOLT (7/16-14X1.125-IN) | 4 | |
| 5M2894 | 48 WASHER-HARD (10.2X18.5X2.5-MM THK) | 18 | |
| 5P4892 | 49 SEAL-O-RING | 3 | |
| 5P5846 | 50 SEAL-O-RING | 1 | |
| 2287097 | 51 SEAL-O-RING | 1 | |
| 5P8244 | 52 WASHER-HARD (12X22.5X2.5-MM THK) | 8 | |
| 6J2244 | 53 SEAL-O-RING | 1 | |
| 6V1573 | 54 CLIP (TAB) | 1 | |
| 6V1572 | 55 CLIP (SLOT) | 1 | |
| 6V3908 | 56 SEAL-O-RING | 1 | |
| 6V4589 | 57 SEAL-O-RING | 2 | |
| 6V5048 | 58 SEAL-O-RING | 1 | |
| 6V6609 | 59 SEAL-O-RING | 1 | |
| 8C3107 | 60 SEAL-O-RING | 1 | |
| 8C3446 | 61 VALVE-SAMPLING | 1 | |
| 8T6762 | 62 PLUG-PIPE (1/2-14-THD) | 1 | |
| 8T6765 | 63 PLUG-PIPE (1/4-18-THD) | 1 | |
| 9S4185 | 64 PLUG (3/4-16-THD) | 1 | |
| 9S4190 | 65 PLUG-O-RING (7/8-14-THD) | 2 | |
| 2768430 | 66 BRACKET | 1 | |
| 1C2251 | 67 BOLT (3/8-16X1.87-IN) | 1 | |
| 9S8752 | 68 NUT-FULL (3/8-16-THD) | 1 |
