System And Components
272-6983 LINES GP-TURBOCHARGER OILS/N SBK1-UP
Group No: 272-6983
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7N5094 | 1 ELBOW-DRAIN | 4 | |
| 1123540 | 2 SEAL-O-RING | 8 | |
| 2934879 | 3 TUBE-TURBOCHARGER | 1 | |
| 2934880 | 4 TUBE-TURBOCHARGER | 2 | |
| 6K5535 | 5 CLIP (SLOT) | 4 | |
| 6K5536 | 6 CLIP (TAB) | 4 | |
| 0S1594 | 7 BOLT (3/8-16X1-IN) | 4 | |
| 1163266 | 8 BRACKET | 4 | |
| 9S8752 | 9 NUT-FULL (3/8-16-THD) | 4 | |
| 9L9132 | 10 WASHER-HARD (10.2X25.5X2.5-MM THK) | 8 | |
| 2B2694 | 11 BOLT (5/16-18X2-IN) | 12 | |
| 9N0869 | 12 WASHER-HARD (8.8X25.5X2-MM THK) | 16 | |
| 1153499 | 13 ELBOW | 4 | |
| 1S4810 | 14 GASKET-OIL DRAIN | 4 | |
| 0S1588 | 15 BOLT (3/8-16X1.25-IN) | 20 | |
| 2W0752 | 16 GASKET | 4 | |
| 3535133 | 17 ELBOW AS | 1 | |
| 0307949 | ELBOW | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 1118906 | 19 ADAPTER-TURBOCHARGER OIL | 4 | |
| 4773333 | 20 HOSE AS | 4 | |
| 0038581 | 21 TEE-UNION | 2 | |
| 1S6595 | 22 GASKET-OIL SUPPLY | 4 | |
| 3650576 | 23 CONNECTOR AS | 1 | |
| 9M4584 | CONNECTOR | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 0T0065 | 24 BOLT (3/8-16X3.5-IN) | 4 | |
| 1118916 | 25 TUBE AS | 1 | |
| 1118909 | 26 TUBE AS | 1 | |
| 9Y0047 | 27 CLAMP | 28 | |
| 2258574 | 28 TUBE AS | 2 | |
| 0T0573 | 29 BOLT (3/8-16X2.75-IN) | 8 | |
| 1003237 | 30 GROMMET | 28 | |
| 0304285 | 32 CONNECTOR | 4 | |
| 2501496 | 33 ELBOW | 2 | |
| 1D4538 | 34 BOLT (5/16-18X2.25-IN) | 2 | |
| 5S0003 | 35 NUT (5/16-18-THD) | 2 | |
| 2934881 | 36 TUBE-TURBOCHARGER | 1 | |
| 2385080 | 37 SEAL-O-RING | 4 |
