System And Components
360-8830 AIR CLEANER GPS/N SBK1-UP
Group No: 360-8830
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7X2153 | 1 HOSE | 1 | |
| 1454211 | 2 ADAPTER AS-FILTER | 1 | |
| 1501714 | 3 PRECLEANER GP (AIR CLEANER) | 1 | |
| 1505030 | 4 INDICATOR-AIR FILTER CHANGE | 1 | |
| 2103257 | 5 ELBOW | 1 | |
| 2566453 | 6 SENSOR-TEMPERATURE (2-PIN)(AMBIENT AIR TEMP) | 1 | |
| 3499114 | 7 TUBE AS | 1 | |
| 3540476 | 8 BRACE | 1 | |
| 3540477 | 9 BRACE | 1 | |
| 3606849 | 10 AIR CLEANER GP | 1 | |
| 4616207 | 11 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 2 | |
| 3K0360 | 12 SEAL-O-RING | 1 | |
| 4L6454 | 13 BOLT (3/8-16X1-IN) | 6 | |
| 5P1075 | 14 WASHER-HARD (10.2X22.5X3-MM THK) | 6 | |
| 5P1076 | 15 WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 7X0366 | 16 BOLT (3/4-10X2-IN) | 2 | |
| 7X0582 | 17 WASHER-HARD (20X44.5X6-MM THK) | 2 | |
| 8T4139 | 18 BOLT (M12X1.75X30-MM) | 4 | |
| 8T4988 | 19 CLAMP-HOSE | 3 | |
| 8T4989 | 20 CLAMP-HOSE | 1 |
