274-1741 LINES GP-AIR -ATAAC INLETS/N SBK200-201; SBK212-UP

Group No: 274-1741
Part NumberPart NameQty
1S43051 SPACER (0.531X1X0.56-IN THK)8
7N69862 SUPPORT1
13562613 CLAMP24
13641904 CLIP-2 PIECE6
13641915 CLIP-2 PIECE6
26653606 WASHER (13X37X3-MM THK)4
27335387 HOSE6
27335408 TUBE2
27417379 BRACKET6
282666610 SUPPORT AS2
282666911 SUPPORT AS2
282667012 SUPPORT1
282667913 CLAMP16
282668014 STRAP8
282991715 TUBE1
282991816 TUBE1
293980917 CLIP-2 PIECE2
293981018 CLIP-2 PIECE2
294524919 BRACKET (LH)1
294525020 BRACKET (RH)1
295284721 BRACKET (LH)1
295284822 BRACKET (RH)1
315533823 STRAP4
315534124 CLAMP2
315534425 CLAMP2
5P107526 WASHER-HARD (10.2X22.5X3-MM THK)22
5P107627 WASHER-HARD (13.5X30X4-MM THK)8
5P222828 BOLT (1/2-13X1-IN)4
5P256629 BOLT (1/2-13X1.5-IN)16
6V443030 SEAL-O-RING16
6V818831 NUT (1/2-13-THD)28
6V880132 NUT (3/8-16-THD)18
7X031133 BOLT (7/16-14X2.25-IN)4
7X034534 BOLT (5/8-11X1.75-IN)12
7X044735 NUT (7/16-14-THD)6
7X044836 NUT (5/8-11-THD)12
7X058937 WASHER-HARD (12X28.5X5-MM THK)2
8C443638 BOLT (1/2-13X1.375-IN)6
7F019239 BOLT (3/8-16X2-IN)10
8T250240 BOLT (3/8-16X1.125-IN)6
8T412241 WASHER-HARD (17X32X3.5-MM THK)24
8T422342 WASHER-HARD (13.5X25.5X3-MM THK)52
8T483543 BOLT (1/2-13X2-IN)2
8T489644 WASHER-HARD (10.2X18.5X2.5-MM THK)15
8T536045 WASHER (12X22.5X2.5-MM THK)10
8T891646 BOLT (7/16-14X1.5-IN)6
8T891947 BOLT (1/2-13X1.75-IN)4
8T937948 BOLT (3/8-16X4.25-IN)2
4L933749 BOLT (3/8-16X1.5-IN)2
