System And Components
274-1741 LINES GP-AIR -ATAAC INLETS/N SBK1-UP
Group No: 274-1741
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1S4305 | 1 SPACER (0.531X1X0.56-IN THK) | 8 | |
| 1356261 | 3 CLAMP | 24 | |
| 1364190 | 4 CLIP-2 PIECE | 6 | |
| 1364191 | 5 CLIP-2 PIECE | 6 | |
| 2665360 | 6 WASHER (13X37X3-MM THK) | 4 | |
| 3668500 | 7 HOSE | 6 | |
| 2733540 | 8 TUBE | 2 | |
| 2741737 | 9 BRACKET | 6 | |
| 2826666 | 10 SUPPORT AS | 2 | |
| 2826670 | 12 SUPPORT | 1 | |
| 2826679 | 13 CLAMP | 16 | |
| 2826680 | 14 STRAP | 8 | |
| 2829917 | 15 TUBE | 1 | |
| 2829918 | 16 TUBE | 1 | |
| 2939809 | 17 CLIP-2 PIECE | 2 | |
| 2939810 | 18 CLIP-2 PIECE | 2 | |
| 2945249 | 19 BRACKET (LH) | 1 | |
| 2945250 | 20 BRACKET (RH) | 1 | |
| 2952847 | 21 BRACKET (LH) | 1 | |
| 2952848 | 22 BRACKET (RH) | 1 | |
| 3155338 | 23 STRAP | 4 | |
| 3155341 | 24 CLAMP | 2 | |
| 3155344 | 25 CLAMP | 2 | |
| 5P1075 | 26 WASHER-HARD (10.2X22.5X3-MM THK) | 20 | |
| 5P1076 | 27 WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 6C3241 | 29 BOLT (1/2-13X1.5-IN) | 16 | |
| 6V4430 | 30 SEAL-O-RING | 16 | |
| 6V8188 | 31 NUT (1/2-13-THD) | 26 | |
| 6V8801 | 32 NUT (3/8-16-THD) | 16 | |
| 7X0311 | 33 BOLT (7/16-14X2.25-IN) | 4 | |
| 7X0345 | 34 BOLT (5/8-11X1.75-IN) | 12 | |
| 7X0447 | 35 NUT (7/16-14-THD) | 6 | |
| 7X0448 | 36 NUT (5/8-11-THD) | 12 | |
| 8C4436 | 38 BOLT (1/2-13X1.375-IN) | 4 | |
| 7F0192 | 39 BOLT (3/8-16X2-IN) | 10 | |
| 8T2502 | 40 BOLT (3/8-16X1.125-IN) | 6 | |
| 8T4122 | 41 WASHER-HARD (17X32X3.5-MM THK) | 24 | |
| 8T4223 | 42 WASHER-HARD (13.5X25.5X3-MM THK) | 52 | |
| 5P2424 | 43 BOLT (1/2-13X2.25-IN) | 2 | |
| 8T4896 | 44 WASHER-HARD (10.2X18.5X2.5-MM THK) | 12 | |
| 8T5360 | 45 WASHER (12X22.5X2.5-MM THK) | 8 | |
| 8T8916 | 46 BOLT (7/16-14X1.5-IN) | 6 | |
| 8T8919 | 47 BOLT (1/2-13X1.75-IN) | 4 |
