295-6338 LINES GP-AIR -ATAAC INLETS/N SBK1-UP

Group No: 295-6338
Part NumberPart NameQty
1S43051 SPACER (0.531X1X0.56-IN THK)8
7N69862 SUPPORT1
13562613 CLAMP24
13641904 CLIP-2 PIECE6
13641915 CLIP-2 PIECE6
26653606 WASHER (13X37X3-MM THK)4
36685007 HOSE6
27335408 TUBE2
28266799 CLAMP16
282668010 STRAP8
282991711 TUBE1
282991812 TUBE1
293980913 CLIP-2 PIECE2
293981014 CLIP-2 PIECE2
294524915 BRACKET (LH)1
294525016 BRACKET (RH)1
295284717 BRACKET (LH)1
295284818 BRACKET (RH)1
295634219 SUPPORT AS2
295925420 SUPPORT1
295925521 SUPPORT AS2
295925722 BRACKET1
295925823 BRACKET1
296750524 BRACKET4
315533825 STRAP4
315534126 CLAMP2
315534427 CLAMP2
5P107528 WASHER-HARD (10.2X22.5X3-MM THK)22
5P107629 WASHER-HARD (13.5X30X4-MM THK)8
5P222830 BOLT (1/2-13X1-IN)4
6C324131 BOLT (1/2-13X1.5-IN)16
7F019232 BOLT (3/8-16X2-IN)4
6V443033 SEAL-O-RING16
6V818834 NUT (1/2-13-THD)28
6V880135 NUT (3/8-16-THD)18
7X031136 BOLT (7/16-14X2.25-IN)4
7X034537 BOLT (5/8-11X1.75-IN)12
7X044738 NUT (7/16-14-THD)6
7X044839 NUT (5/8-11-THD)12
7X058940 WASHER-HARD (12X28.5X5-MM THK)2
8C443641 BOLT (1/2-13X1.375-IN)6
8T250142 BOLT (3/8-16X2-IN)6
8T250243 BOLT (3/8-16X1.125-IN)6
8T412244 WASHER-HARD (17X32X3.5-MM THK)24
8T422345 WASHER-HARD (13.5X25.5X3-MM THK)52
8T489646 WASHER-HARD (10.2X18.5X2.5-MM THK)15
8T536047 WASHER (12X22.5X2.5-MM THK)10
8T891648 BOLT (7/16-14X1.5-IN)2
8T891949 BOLT (1/2-13X1.75-IN)4
8T937950 BOLT (3/8-16X4.25-IN)2
4L933751 BOLT (3/8-16X1.5-IN)2
5P242452 BOLT (1/2-13X2.25-IN)2
