System And Components
525-7740 LINES GP-AIRS/N SBK1-UP
Group No: 525-7740
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7F0192 | 1 BOLT (3/8-16X2-IN) | 10 | |
| 1356261 | 2 CLAMP | 24 | |
| 1364190 | 3 CLIP-2 PIECE | 6 | |
| 1364191 | 4 CLIP-2 PIECE | 6 | |
| 2665360 | 5 WASHER (13X37X3-MM THK) | 4 | |
| 2733540 | 6 TUBE | 2 | |
| 2741737 | 7 BRACKET | 6 | |
| 2826666 | 8 SUPPORT AS | 2 | |
| 2826670 | 9 SUPPORT | 1 | |
| 2826679 | 10 CLAMP (SADDLE) | 16 | |
| 2826680 | 11 STRAP | 8 | |
| 2939809 | 12 CLIP-2 PIECE | 2 | |
| 2939810 | 13 CLIP-2 PIECE | 2 | |
| 2945249 | 14 BRACKET (LH) | 1 | |
| 2945250 | 15 BRACKET (RH) | 1 | |
| 2952847 | 16 BRACKET (LH) | 1 | |
| 2952848 | 17 BRACKET (RH) | 1 | |
| 3155338 | 18 STRAP | 4 | |
| 3155341 | 19 CLAMP | 2 | |
| 3155344 | 20 CLAMP | 2 | |
| 3668500 | 21 HOSE | 6 | |
| 5257741 | 22 TUBE (LH) | 1 | |
| 5257742 | 23 TUBE (RH) | 1 | |
| 1S4305 | 24 SPACER (0.531X1X0.56-IN THK) | 8 | |
| 5P1075 | 25 WASHER-HARD (10.2X22.5X3-MM THK) | 20 | |
| 5P1076 | 26 WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 5P2424 | 27 BOLT (1/2-13X2.25-IN) | 2 | |
| 6C3241 | 28 BOLT (1/2-13X1.5-IN) | 16 | |
| 6V4430 | 29 SEAL-O-RING | 16 | |
| 6V8188 | 30 NUT (1/2-13-THD) | 26 | |
| 6V8801 | 31 NUT (3/8-16-THD) | 16 | |
| 7X0311 | 32 BOLT (7/16-14X2.25-IN) | 4 | |
| 7X0345 | 33 BOLT (5/8-11X1.75-IN) | 12 | |
| 7X0447 | 34 NUT (7/16-14-THD) | 6 | |
| 7X0448 | 35 NUT (5/8-11-THD) | 12 | |
| 8C4436 | 36 BOLT (1/2-13X1.375-IN) | 4 | |
| 8T2502 | 37 BOLT (3/8-16X1.125-IN) | 6 | |
| 8T4122 | 38 WASHER-HARD (17X32X3.5-MM THK) | 24 | |
| 8T4223 | 39 WASHER-HARD (13.5X25.5X3-MM THK) | 52 | |
| 8T4896 | 40 WASHER-HARD (10.2X18.5X2.5-MM THK) | 12 | |
| 8T5360 | 41 WASHER (12X22.5X2.5-MM THK) | 8 | |
| 8T8916 | 42 BOLT (7/16-14X1.5-IN) | 6 | |
| 8T8919 | 43 BOLT (1/2-13X1.75-IN) | 4 |
