System And Components
280-3332 MOUNTING GP-AIR CLEANERS/N SBK1-UP
Group No: 280-3332
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P3860 | 1 CLAMP-HOSE | 4 | |
| 5P4869 | 2 CLAMP-HOSE | 12 | |
| 6I0133 | 3 BRACKET AS | 2 | |
| 3215895 | 4 SHIELD AS | 4 | |
| 7N6986 | 5 SUPPORT | 4 | |
| 8N5254 | 7 HOSE-REDUCER | 4 | |
| 8N8741 | 8 HOSE | 4 | |
| 1131328 | 9 TUBE | 2 | |
| 1131570 | 10 BRACKET AS (LH) | 1 | |
| 1131571 | 11 CRADLE AS | 2 | |
| 1131573 | 12 BRACKET AS (RH) | 1 | |
| 1916015 | 14 BRACKET | 4 | |
| 4529342 | 15 CLAMP AS | 4 | |
| 2773601 | 16 TUBE AS | 2 | |
| 0L1351 | 17 BOLT (3/8-16X0.875-IN) | 6 | |
| 0S1588 | 18 BOLT (3/8-16X1.25-IN) | 6 | |
| 1653929 | 19 BOLT (3/8-16X1.5-IN) | 2 | |
| 0S1594 | 20 BOLT (3/8-16X1-IN) | 8 | |
| 0T0055 | 21 BOLT (3/8-16X4.25-IN) | 8 | |
| 1A2029 | 22 BOLT (3/8-16X1.125-IN) | 22 | |
| 2K4973 | 23 LOCKNUT (3/8-16-THD) | 8 | |
| 3B1915 | 24 BOLT (3/8-16X1.375-IN) | 8 | |
| 5M2894 | 25 WASHER-HARD (10.2X18.5X2.5-MM THK) | 38 | |
| 6H1717 | 26 BOLT (1/2-13X1.125-IN) | 12 | |
| 7D1649 | 27 WASHER-HARD (13.5X32X5-MM THK) | 12 | |
| 9S8752 | 28 NUT-FULL (3/8-16-THD) | 16 | |
| 9X6458 | 29 WASHER-HARD (10.2X22.5X3-MM THK) | 30 |
