System And Components
120-4491 PRECLEANER GPS/N SBK1-UP
Group No: 120-4491
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1S5485 | 1 VALVE-DUST | 3 | |
| 2W9069 | 2 CUP AS-PRECLEANER | 3 | |
| 7E7379 | 3 SHIELD (FRONT) | 1 | |
| 1S5465 | 4 GUARD-DUST | 3 | |
| 7E7380 | 5 SHIELD (LH) | 1 | |
| 7E7376 | 6 BODY AS | 1 | |
| 2M0879 | 7 SEAL-O-RING | 3 | |
| 7E7378 | 8 SHIELD (RH) | 1 | |
| 9M7959 | 9 CLAMP-HOSE | 3 | |
| 5N7834 | 10 CLAMP AS | 3 | |
| 1204490 | 11 ADAPTER AS | 1 | |
| 8T2502 | 12 BOLT (3/8-16X1.125-IN) | 22 | |
| 8T4896 | 13 WASHER-HARD (10.2X18.5X2.5-MM THK) | 44 | |
| 6V8801 | 14 NUT (3/8-16-THD) | 22 | |
| 7W9857 | 15 GASKET | 2 | |
| 7E7377 | 16 GASKET | 2 |
