System And Components
295-1557 FILTER & LINES GP-ENGINE OILS/N JHL1-UP
Group No: 295-1557
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1B8704 | 1 KEY-WOODRUFF | 2 | |
| 1R1808 | 2 FILTER-ENGINE OIL (ADVANCED EFFICIENCY) | 2 | |
| 2N0178 | 3 PANEL | 1 | |
| 2N0179 | 4 COVER-PANEL | 1 | |
| 2N5848 | 5 BASE AS | 1 | |
| 2P3760 | 6 GASKET | 2 | |
| 2P3761 | 7 COVER | 2 | |
| 2P4301 | 8 BASE AS-OIL FILTER | 2 | |
| 2P4304 | STUD-HOLLOW | 1 | |
| 2P4305 | 9 GASKET | 4 | |
| 2W3681 | 10 INDICATOR AS (ENGINE OIL PRESSURE) | 2 | |
| 4H9756 | 11 LEVER-RELEASE CONTROL | 1 | |
| 4N7082 | 12 SHIELD-OIL FILTER | 2 | |
| 4N8150 | 13 SPRING | 2 | |
| 5L5709 | 14 CONNECTOR-SHIELD | 1 | |
| 6N0824 | 16 GASKET | 1 | |
| 6N1258 | 17 HOUSING | 1 | |
| 6N1259 | 18 POINTER | 1 | |
| 7C0824 | 19 HOSE AS | 2 | |
| 7N0912 | 20 VALVE GP-FLUID CONTROL (ENGINE OIL) | 1 | |
| 3F9190 | PIN | 1 | |
| 7N0911 | VALVE AS | 1 | |
| 7N0914 | 21 DETENT AS | 1 | |
| 6J8356 | SPRING | 2 | |
| 6N4204 | PIN | 2 | |
| 6N4205 | PLATE | 1 | |
| 7N0913 | RING | 1 | |
| 8F8833 | PIN | 1 | |
| 7W2731 | 22 RETAINER | 2 | |
| 8C3445 | 23 CAP-DUST | 1 | |
| 9M0853 | 24 PLUNGER-VALVE (OIL COOLER) | 2 | |
| 1882866 | 25 HOSE AS | 1 | |
| 1889834 | 26 HOSE AS | 1 | |
| 2112048 | 27 COVER | 1 | |
| 2116801 | 28 HOSE AS | 1 | |
| 2433384 | 29 BRACKET | 1 | |
| 2433396 | 30 BRACKET AS | 1 | |
| 2501424 | 31 ELBOW AS | 2 | |
| 6V8724 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2213494 | SEAL-O-RING | 1 | |
| 2560811 | 32 ADAPTER | 1 | |
| 2579878 | 33 CONNECTOR | 1 | |
| 2928184 | 34 COVER | 1 | |
| 2928185 | 35 ADAPTER | 1 | |
| 2928186 | 36 COVER AS | 1 | |
| 2955782 | 37 TUBE AS | 1 | |
| 2955783 | 38 BRACKET AS | 1 | |
| 3113065 | 39 BRACKET AS | 1 | |
| 3113066 | 40 BRACKET AS | 1 | |
| 3113067 | 41 TUBE AS | 1 | |
| 3149335 | 42 TUBE AS | 1 | |
| 3156142 | 43 TUBE AS | 1 | |
| 0618639 | 44 SEAL-O-RING | 1 | |
| 0S1571 | 45 BOLT (3/8-16X1.75-IN) | 1 | |
| 0S1588 | 46 BOLT (3/8-16X1.25-IN) | 4 | |
| 0S1591 | 47 BOLT (3/8-16X1.5-IN) | 4 | |
| 0S1594 | 48 BOLT (3/8-16X1-IN) | 5 | |
| 1090078 | 49 SEAL-O-RING | 1 | |
| 1488458 | 50 UNION AS (ORFS) | 2 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V9807 | UNION | 1 | |
| 1645570 | 51 UNION AS | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8730 | UNION (FACE SEAL) | 1 | |
| 1646875 | 52 ELBOW AS | 2 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 0307946 | ELBOW | 1 | |
| 1A2029 | 53 BOLT (3/8-16X1.125-IN) | 1 | |
| 8C6876 | 54 BOLT (5/16-18X1.625-IN) | 1 | |
| 1L6561 | 55 PLUG | 1 | |
| 2A4639 | 56 BOLT (3/8-16X1.625-IN) | 8 | |
| 2M1538 | 57 STUD-TAPERLOCK (3/8-16X1.6-IN) | 8 | |
| 5P4116 | 58 WASHER-HARD (8.8X20.5X2-MM THK) | 1 | |
| 3P0656 | 60 SEAL-O-RING | 1 | |
| 4B2041 | 61 NUT (6-32-THD) | 2 | |
| 4B5324 | 62 WASHER (3.9X9.6X1.2-MM THK) | 4 | |
| 4L6454 | 63 BOLT (3/8-16X1-IN) | 2 | |
| 4M0061 | 64 BOLT (5/16-18X0.75-IN) | 1 | |
| 5L5502 | 65 FITTING | 1 | |
| 5M2894 | 66 WASHER-HARD (10.2X18.5X2.5-MM THK) | 48 | |
| 8T2502 | 67 BOLT (3/8-16X1.125-IN) | 1 | |
| 5P1075 | 68 WASHER-HARD (10.2X22.5X3-MM THK) | 4 | |
| 5S7348 | 70 SCREW-MACHINE (6-32X0.375-IN) | 2 | |
| 6V3265 | 71 CLIP | 2 | |
| 6V3507 | 72 SEAL-RECTANGULAR | 2 | |
| 6V3908 | 73 SEAL-O-RING | 3 | |
| 6V8185 | 75 NUT (1/4-20-THD) | 3 | |
| 6V8397 | 76 SEAL-O-RING | 1 | |
| 6V8801 | 78 NUT (3/8-16-THD) | 2 | |
| 1488356 | 79 ELBOW AS | 3 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 6V8400 | SEAL-O-RING | 1 | |
| 6V9009 | ELBOW | 1 | |
| 1488326 | 80 CONNECTOR AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9872 | CONNECTOR | 1 | |
| 7F3425 | 81 BOLT (3/8-16X5.75-IN) | 4 | |
| 7F9090 | 82 SCREW-DRIVE (NO 8X3/8-IN) | 4 | |
| 7N3718 | 83 CLIP | 1 | |
| 7X2501 | 84 BOLT (1/4-20X1.25-IN) | 3 | |
| 8B4884 | 85 ELBOW | 2 | |
| 3218649 | 86 VALVE AS-FLUID SAMPLING | 1 | |
| 8C3446 | VALVE-SAMPLING | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 8T4205 | 87 WASHER-HARD (7.2X14.5X2-MM THK) | 9 | |
| 8T4224 | 88 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 8T4896 | 89 WASHER-HARD (10.2X18.5X2.5-MM THK) | 5 | |
| 1553624 | 90 PLUG AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 9S4182 | PLUG (7/16-20-THD) | 1 | |
| 9S8752 | 91 NUT-FULL (3/8-16-THD) | 26 |
