System And Components
295-6141 FILTER & LINES GP-ENGINE OILS/N JHL1-UP
Group No: 295-6141
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1B8704 | 1 KEY-WOODRUFF | 2 | |
| 1R1808 | 2 FILTER-ENGINE OIL (ADVANCED EFFICIENCY) | 2 | |
| 2N0178 | 3 PANEL | 1 | |
| 2N0179 | 4 COVER-PANEL | 1 | |
| 2N5848 | 5 BASE AS | 1 | |
| 2P3760 | 6 GASKET | 2 | |
| 2P3761 | 7 COVER | 2 | |
| 2P4301 | 8 BASE AS-OIL FILTER | 2 | |
| 2P4304 | STUD-HOLLOW | 1 | |
| 2P4305 | 9 GASKET | 4 | |
| 2926476 | 10 CLAMP | 4 | |
| 2W3681 | 11 INDICATOR AS (ENGINE OIL PRESSURE) | 2 | |
| 3N4579 | 12 HOSE AS | 2 | |
| 4H9756 | 13 LEVER-RELEASE CONTROL | 1 | |
| 4N7082 | 14 SHIELD-OIL FILTER | 2 | |
| 4N8150 | 15 SPRING | 2 | |
| 6N0824 | 17 GASKET | 2 | |
| 6N1258 | 18 HOUSING | 1 | |
| 6N1259 | 19 POINTER | 1 | |
| 7N0912 | 20 VALVE GP-FLUID CONTROL (ENGINE OIL) | 1 | |
| 3F9190 | PIN | 1 | |
| 7N0911 | VALVE AS | 1 | |
| 7N0914 | 21 DETENT AS | 1 | |
| 6J8356 | SPRING | 2 | |
| 6N4204 | PIN | 2 | |
| 6N4205 | PLATE | 1 | |
| 7N0913 | RING | 1 | |
| 8F8833 | PIN | 1 | |
| 7W2731 | 22 RETAINER | 2 | |
| 8C3445 | 23 CAP-DUST | 1 | |
| 3929208 | 24 PLUNGER-VALVE (RELIEF)(OIL COOLER) | 2 | |
| 1804132 | 25 HOSE AS | 1 | |
| 2112048 | 26 COVER | 1 | |
| 2433385 | 27 BRACKET | 1 | |
| 2433808 | 28 BRACKET AS | 1 | |
| 2560811 | 29 ADAPTER | 1 | |
| 2579878 | 30 CONNECTOR | 1 | |
| 2928184 | 31 COVER | 1 | |
| 2928185 | 32 ADAPTER | 1 | |
| 2928186 | 33 COVER AS | 2 | |
| 2956144 | 34 TUBE AS | 1 | |
| 2956145 | 35 TUBE AS | 1 | |
| 2957976 | 36 TUBE AS | 1 | |
| 2957977 | 37 TUBE AS | 1 | |
| 3113065 | 38 BRACKET AS | 1 | |
| 3113066 | 39 BRACKET AS | 1 | |
| 3223639 | 40 TUBE AS | 1 | |
| 3223640 | 41 TUBE AS | 1 | |
| 3233494 | 42 BRACKET | 1 | |
| 1185068 | 43 SEAL-O-RING | 1 | |
| 5S7379 | 44 BOLT (3/8-16X0.875-IN) | 2 | |
| 0S1571 | 45 BOLT (3/8-16X1.75-IN) | 9 | |
| 0S1588 | 46 BOLT (3/8-16X1.25-IN) | 8 | |
| 0S1590 | 47 BOLT (3/8-16X2-IN) | 4 | |
| 4L6454 | 48 BOLT (3/8-16X1-IN) | 3 | |
| 1488326 | 49 CONNECTOR AS | 3 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9872 | CONNECTOR | 1 | |
| 1488334 | 50 CONNECTOR AS | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 6V8400 | SEAL-O-RING | 1 | |
| 8T3611 | CONNECTOR | 1 | |
| 1488356 | 51 ELBOW AS | 3 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 6V8400 | SEAL-O-RING | 1 | |
| 6V9009 | ELBOW | 1 | |
| 1488367 | 52 ELBOW AS | 2 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9850 | ELBOW | 1 | |
| 1542302 | 53 SPACER (11X20X15-MM THK) | 4 | |
| 3072671 | 54 PLUG AS | 1 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 1645570 | 55 UNION AS | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8730 | UNION (FACE SEAL) | 1 | |
| 1645584 | 56 ELBOW AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 7J4026 | ELBOW | 1 | |
| 1860357 | 57 CLIP | 1 | |
| 1L6561 | 58 PLUG | 1 | |
| 2A2677 | 59 SPACER (10.7X17.14X19.05-MM THK) | 1 | |
| 0S1591 | 60 BOLT (3/8-16X1.5-IN) | 4 | |
| 2M1538 | 61 STUD-TAPERLOCK (3/8-16X1.6-IN) | 8 | |
| 3P0656 | 62 SEAL-O-RING | 1 | |
| 4B2041 | 63 NUT (6-32-THD) | 2 | |
| 4B5324 | 64 WASHER (3.9X9.6X1.2-MM THK) | 4 | |
| 5L5502 | 65 FITTING | 1 | |
| 5M2894 | 66 WASHER-HARD (10.2X18.5X2.5-MM THK) | 54 | |
| 8T4205 | 67 WASHER-HARD (7.2X14.5X2-MM THK) | 9 | |
| 5S7348 | 68 SCREW-MACHINE (6-32X0.375-IN) | 2 | |
| 6D9392 | 69 CLAMP | 4 | |
| 6V3507 | 70 SEAL-RECTANGULAR | 2 | |
| 6V3908 | 71 SEAL-O-RING | 3 | |
| 2287089 | 72 SEAL-O-RING | 1 | |
| 6V8400 | 73 SEAL-O-RING | 2 | |
| 7F3425 | 74 BOLT (3/8-16X5.75-IN) | 4 | |
| 7F9090 | 75 SCREW-DRIVE (NO 8X3/8-IN) | 4 | |
| 8B4884 | 76 ELBOW | 2 | |
| 3218649 | 77 VALVE AS-FLUID SAMPLING (ENGINE OIL) | 1 | |
| 8C3446 | VALVE-SAMPLING | 1 | |
| 2147566 | SEAL-O-RING | 11 | |
| 7X2501 | 78 BOLT (1/4-20X1.25-IN) | 3 | |
| 6V8185 | 79 NUT (1/4-20-THD) | 3 | |
| 9S8752 | 80 NUT-FULL (3/8-16-THD) | 29 | |
| 5S7383 | 81 BOLT (3/8-16X1.75-IN) | 1 | |
| 8T4896 | 82 WASHER-HARD (10.2X18.5X2.5-MM THK) | 10 | |
| 6V8801 | 83 NUT (3/8-16-THD) | 4 | |
| 9X8267 | 84 WASHER (6.6X12X2-MM THK) | 4 | |
| 8T0640 | 85 BOLT (M6X1X30-MM) | 2 | |
| 6V8225 | 86 NUT (M6X1-THD) | 2 |
